TJ2151070000G AMPHENOL ANYTEK
Виробник: AMPHENOL ANYTEKCategory: Pluggable terminal blocks
Description: Connector: pluggable terminal block; plug; female; 12A; 300V; PA66
Colour: black
Operating temperature: -40...115°C
Flammability rating: UL94V-0
Body material: PA66
Number of pins: 21
Contact material: phosphor bronze
Contacts pitch: 5.08mm
Wire size: 24AWG...12AWG
Electrical mounting: screw terminal
Mechanical mounting: for cable; for panel mounting
Spatial orientation: straight
Type of connector: pluggable terminal block
Connector: plug
Kind of connector: female
Contact plating: tinned
Rated voltage: 300V
Current rating: 12A
кількість в упаковці: 1 шт
товару немає в наявності
Відгуки про товар
Написати відгук
Технічний опис TJ2151070000G AMPHENOL ANYTEK
Category: Pluggable terminal blocks, Description: Connector: pluggable terminal block; plug; female; 12A; 300V; PA66, Colour: black, Operating temperature: -40...115°C, Flammability rating: UL94V-0, Body material: PA66, Number of pins: 21, Contact material: phosphor bronze, Contacts pitch: 5.08mm, Wire size: 24AWG...12AWG, Electrical mounting: screw terminal, Mechanical mounting: for cable; for panel mounting, Spatial orientation: straight, Type of connector: pluggable terminal block, Connector: plug, Kind of connector: female, Contact plating: tinned, Rated voltage: 300V, Current rating: 12A, кількість в упаковці: 1 шт.
Інші пропозиції TJ2151070000G
| Фото | Назва | Виробник | Інформація |
Доступність |
Ціна |
|---|---|---|---|---|---|
| TJ2151070000G | Виробник : Amphenol Anytek |
Description: TERM BLOCK PLUG 21POS STR 5.08MM Packaging: Bulk Features: Mating Flange, Retention Latches (Non-Wire Side) Color: Black Mounting Type: Free Hanging (In-Line) Number of Positions: 21 Pitch: 0.200" (5.08mm) Type: Plug, Female Sockets Operating Temperature: -40°C ~ 115°C Termination Style: Screw Number of Levels: 1 Wire Gauge or Range - AWG: 12-24 AWG Positions Per Level: 21 Plug Wire Entry: 180° Contact Mating Finish: Tin Part Status: Active Current - UL: 20 A Voltage - UL: 300 V |
товару немає в наявності |
||
| TJ2151070000G | Виробник : Amphenol Anytek |
Pluggable Terminal Blocks 508 TB PLU PLU WF UP |
товару немає в наявності |
||
|
|
TJ2151070000G | Виробник : AMPHENOL ANYTEK |
Category: Pluggable terminal blocks Description: Connector: pluggable terminal block; plug; female; 12A; 300V; PA66 Colour: black Operating temperature: -40...115°C Flammability rating: UL94V-0 Body material: PA66 Number of pins: 21 Contact material: phosphor bronze Contacts pitch: 5.08mm Wire size: 24AWG...12AWG Electrical mounting: screw terminal Mechanical mounting: for cable; for panel mounting Spatial orientation: straight Type of connector: pluggable terminal block Connector: plug Kind of connector: female Contact plating: tinned Rated voltage: 300V Current rating: 12A |
товару немає в наявності |
