TLW-140-05-G-S Samtec Inc.
Виробник: Samtec Inc.Description: CONN HEADER VERT 40POS 2.54MM
Packaging: Bulk
Connector Type: Header
Current Rating (Amps): 5.2A per Contact
Mounting Type: Through Hole
Number of Positions: 40
Number of Rows: 1
Style: Board to Board or Cable
Operating Temperature: -55°C ~ 125°C
Contact Type: Male Pin
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Contact Material: Phosphor Bronze
Insulation Color: Black
Pitch - Mating: 0.100" (2.54mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 10.0µin (0.25µm)
Contact Finish - Post: Gold
Part Status: Active
Contact Shape: Square
Contact Length - Post: 0.170" (4.32mm)
Insulation Height: 0.060" (1.52mm)
Shrouding: Unshrouded
Overall Contact Length: 0.335" (8.51mm)
Insulation Material: Liquid Crystal Polymer (LCP)
Contact Length - Mating: 0.105" (2.67mm)
на замовлення 5060 шт:
термін постачання 21-31 дні (днів)
| Кількість | Ціна без ПДВ |
|---|---|
| 1+ | 473.71 грн |
| 10+ | 421.83 грн |
| 25+ | 398.98 грн |
| 50+ | 360.72 грн |
| 100+ | 337.62 грн |
Відгуки про товар
Написати відгук
Технічний опис TLW-140-05-G-S Samtec Inc.
Description: CONN HEADER VERT 40POS 2.54MM, Packaging: Bulk, Connector Type: Header, Current Rating (Amps): 5.2A per Contact, Mounting Type: Through Hole, Number of Positions: 40, Number of Rows: 1, Style: Board to Board or Cable, Operating Temperature: -55°C ~ 125°C, Contact Type: Male Pin, Fastening Type: Push-Pull, Number of Positions Loaded: All, Termination: Solder, Contact Material: Phosphor Bronze, Insulation Color: Black, Pitch - Mating: 0.100" (2.54mm), Contact Finish - Mating: Gold, Contact Finish Thickness - Mating: 10.0µin (0.25µm), Contact Finish - Post: Gold, Part Status: Active, Contact Shape: Square, Contact Length - Post: 0.170" (4.32mm), Insulation Height: 0.060" (1.52mm), Shrouding: Unshrouded, Overall Contact Length: 0.335" (8.51mm), Insulation Material: Liquid Crystal Polymer (LCP), Contact Length - Mating: 0.105" (2.67mm).
Інші пропозиції TLW-140-05-G-S за ціною від 444.52 грн до 762.89 грн
| Фото | Назва | Виробник | Інформація |
Доступність |
Ціна без ПДВ | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
TLW-140-05-G-S | Виробник : Samtec |
Headers & Wire Housings .100" Low Profile Terminal Strip |
на замовлення 11 шт: термін постачання 21-30 дні (днів) |
|
