UT139B (UNI-T) True RMS Digital Multimeter Uni-Trend (Uni-T)

Виробник: UNI-T
Category: Portable digital multimeters
Description: Digital multimeter; LCD; (3999); VDC accuracy: ±(0.5%+2digit)
Type of meter: digital multimeter
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; duty cycle; frequency; resistance
Kind of display used: LCD
Display parameters: (3999)
DC voltage measuring range: 40mV; 400mV; 4V; 40V; 400V; 600V
DC voltage measuring accuracy: ±(0.5% + 2 digit)
AC voltage measuring range: 40mV; 400mV; 4V; 40V; 400V; 600V
AC voltage measuring accuracy: ±(0.8% + 3 digit)
DC current measuring range: 0.4mA; 4mA; 40mA; 400mA; 4A; 10A
DC current measuring accuracy: ±(0.7% + 2 digit)
AC current measuring range: 0.4mA; 4mA; 40mA; 400mA; 4A; 10A
AC current measuring accuracy: ±(1% + 3 digit)
True effective value measurement: True RMS
Resistance measuring range: 0.4kΩ; 4kΩ; 40kΩ; 400kΩ; 4MΩ; 40MΩ
Capacitance measuring range: 10nF; 100nF; 1mF; 10mF
Capacitance measuring accuracy: ±(4%+ 5 digit)
Frequency measuring range: 10...10MHz
Frequency measuring accuracy: ±(0.1%+4 digit)
Resistance measuring accuracy: ±(0.8%+2 digit)
Duty cycle factor: 0.1...99.9%
Test: diodes
Continuity test: acoustic indication; <10Ω
Power supply: battery R6 AA 1,5V x2
Standard equipment: holster; test leads
Conform to the norm: CAT III 600V; EN 61010
Dimensions (W x H x D): 80x170x48mm
Measuring instrument features: auto and manual ranging; automatic power-off; contactless voltage detector; HOLD function; low battery indicator; MIN/MAX/REL function
Battery/ rechargeable battery: battery R6 AA 1,5V x2
Illumination: yes
