UT890D + (UNI-T) (Мультиметр) Uni-Trend (Uni-T)

Виробник: UNI-T
Category: Portable digital multimeters
Description: Digital multimeter; LCD; (6000); VDC: 600mV,6V,60V,600V,1kV
Measuring instrument features: automatic power-off; contactless voltage detector; HOLD function; low battery indicator; MIN/MAX function; overflow indicator; REL function
Display parameters: (6000)
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance; transistors' gain h_FE
Continuity test: acoustic indication; <10Ω
Power supply: battery AAA 1,5V x2
Battery/ rechargeable battery: battery AAA 1,5V x2
Standard equipment: test leads
Conform to the norm: CAT II 1000V; CAT III 600V; EN 61010
Type of meter: digital multimeter
Kind of display used: LCD
True effective value measurement: True RMS
Illumination: yes
Capacitance measuring range: 6nF; 60nF; 600nF; 6µF; 60µF; 600µF; 6mF; 60mF; 100mF
Diode test: 0...3V
DC current measuring range: 60µA; 600µA; 6mA; 60mA; 600mA; 20A
Operating temperature: 0...40°C
Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 60MΩ
AC current measuring range: 60µA; 600µA; 6mA; 60mA; 600mA; 20A
DC voltage measuring range: 600mV; 6V; 60V; 600V; 1kV
AC voltage measuring range: 6V; 60V; 600V; 750V
Dimensions (W x H x D): 88x183x56mm
Frequency measuring accuracy: ±(1%+5 digit)
DC voltage measuring accuracy: ±(0.5% + 2 digit)
Capacitance measuring accuracy: ±(3%+ 10 digit)
AC voltage measuring accuracy: ±(0.8% + 3 digit)
Resistance measuring accuracy: ±(0.8%+3 digit)
DC current measuring accuracy: ±(0.8% + 8 digit)
AC current measuring accuracy: ±(1% + 12 digit)
Frequency measuring range: 10...10MHz
