Технічний опис MF40201V1-1000U-A99 Sunon
Category: DC12V Fans, Description: Fan: DC; axial; 12VDC; 40x40x20mm; 15.04m3/h; 25.5dBA; Vapo; 7000rpm, Type of fan: DC, Kind of fan: axial, Supply voltage: 12V DC, Operating voltage: 4.5...13.8V DC, Fan dimensions: 40x40x20mm, Power consumption: 0.7W, Current rating: 58mA, Fan efficiency: 15.04m3/h, Noise level: 25.5dBA, Kind of Bearing: Vapo, Rotational rate/speed: 7000rpm, Min. insulation resistance: 10MΩ, Impeller material: thermoplastic, Enclosure material: thermoplastic, Insulation class: A, Leads: leads x2, Lead length: 0.305m, Operating temperature: -10...70°C, Flammability rating: UL94V-0, Additional functions: autorestart, Fan motor: brushless DC, Static pressure: 5.59mm H2O, Wire size: 26AWG.
Інші пропозиції MF40201V1-1000U-A99 за ціною від 181.15 грн до 688.04 грн
| Фото | Назва | Виробник | Інформація | Доступність | Ціна без ПДВ | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
MF40201V1-1000U-A99 | SUNON |
 Category: DC12V FansDescription: Fan: DC; axial; 12VDC; 40x40x20mm; 15.04m3/h; 25.5dBA; Vapo; 7000rpm Type of fan: DC Kind of fan: axial Supply voltage: 12V DC Operating voltage: 4.5...13.8V DC Fan dimensions: 40x40x20mm Power consumption: 0.7W Current rating: 58mA Fan efficiency: 15.04m3/h Noise level: 25.5dBA Kind of Bearing: Vapo Rotational rate/speed: 7000rpm Min. insulation resistance: 10MΩ Impeller material: thermoplastic Enclosure material: thermoplastic Insulation class: A Leads: leads x2 Lead length: 0.305m Operating temperature: -10...70°C Flammability rating: UL94V-0 Additional functions: autorestart Fan motor: brushless DC Static pressure: 5.59mm H2O Wire size: 26AWG |
на замовлення 1313 шт: термін постачання 14-30 дні (днів) |
|
||||||||||
 |
MF40201V1-1000U-A99 | Sunon Fans |
Description: FAN AXIAL 40X20MM 12VDC WIRE Features: Auto Restart Packaging: Bulk Voltage - Rated: 12VDC Size / Dimension: Square - 40mm L x 40mm H Bearing Type: Vapo-Bearing™ RPM: 7000 RPM Air Flow: 8.9 CFM (0.249m³/min) Width: 20.00mm Weight: 0.064 lb (29.03 g) Operating Temperature: 14 ~ 158°F (-10 ~ 70°C) Termination: 2 Wire Leads Approval Agency: cURus, TUV Fan Type: Tubeaxial Noise: 25.5dB(A) Static Pressure: 0.220 in H2O (54.8 Pa) Part Status: Active Power (Watts): 700 mW |
на замовлення 1359 шт: термін постачання 21-31 дні (днів) |
|
||||||||||
| MF40201V1-1000U-A99 | Sunon |
Mag Lev Motor Fan |
на замовлення 180 шт: термін постачання 21-31 дні (днів) |
|
| MF40201V1-1000U-A99 |
|
Виробник: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x20mm; 15.04m3/h; 25.5dBA; Vapo; 7000rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 4.5...13.8V DC
Fan dimensions: 40x40x20mm
Power consumption: 0.7W
Current rating: 58mA
Fan efficiency: 15.04m3/h
Noise level: 25.5dBA
Kind of Bearing: Vapo
Rotational rate/speed: 7000rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x2
Lead length: 0.305m
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Static pressure: 5.59mm H2O
Wire size: 26AWG
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x20mm; 15.04m3/h; 25.5dBA; Vapo; 7000rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 4.5...13.8V DC
Fan dimensions: 40x40x20mm
Power consumption: 0.7W
Current rating: 58mA
Fan efficiency: 15.04m3/h
Noise level: 25.5dBA
Kind of Bearing: Vapo
Rotational rate/speed: 7000rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x2
Lead length: 0.305m
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Static pressure: 5.59mm H2O
Wire size: 26AWG
на замовлення 1313 шт:
термін постачання 14-30 дні (днів)
| Кількість | Ціна без ПДВ |
|---|---|
| 2+ | 289.90 грн |
| 50+ | 209.93 грн |
| 100+ | 188.77 грн |
| 200+ | 181.15 грн |
| MF40201V1-1000U-A99 |
|
Виробник: Sunon Fans
Description: FAN AXIAL 40X20MM 12VDC WIRE
Features: Auto Restart
Packaging: Bulk
Voltage - Rated: 12VDC
Size / Dimension: Square - 40mm L x 40mm H
Bearing Type: Vapo-Bearing™
RPM: 7000 RPM
Air Flow: 8.9 CFM (0.249m³/min)
Width: 20.00mm
Weight: 0.064 lb (29.03 g)
Operating Temperature: 14 ~ 158°F (-10 ~ 70°C)
Termination: 2 Wire Leads
Approval Agency: cURus, TUV
Fan Type: Tubeaxial
Noise: 25.5dB(A)
Static Pressure: 0.220 in H2O (54.8 Pa)
Part Status: Active
Power (Watts): 700 mW
Description: FAN AXIAL 40X20MM 12VDC WIRE
Features: Auto Restart
Packaging: Bulk
Voltage - Rated: 12VDC
Size / Dimension: Square - 40mm L x 40mm H
Bearing Type: Vapo-Bearing™
RPM: 7000 RPM
Air Flow: 8.9 CFM (0.249m³/min)
Width: 20.00mm
Weight: 0.064 lb (29.03 g)
Operating Temperature: 14 ~ 158°F (-10 ~ 70°C)
Termination: 2 Wire Leads
Approval Agency: cURus, TUV
Fan Type: Tubeaxial
Noise: 25.5dB(A)
Static Pressure: 0.220 in H2O (54.8 Pa)
Part Status: Active
Power (Watts): 700 mW
на замовлення 1359 шт:
термін постачання 21-31 дні (днів)
| Кількість | Ціна без ПДВ |
|---|---|
| 1+ | 624.23 грн |
| 10+ | 487.90 грн |
| 25+ | 445.32 грн |
| 50+ | 389.19 грн |
| 200+ | 348.66 грн |
| MF40201V1-1000U-A99 |
|
Виробник: Sunon
Mag Lev Motor Fan
Mag Lev Motor Fan
на замовлення 180 шт:
термін постачання 21-31 дні (днів)
| Кількість | Ціна без ПДВ |
|---|---|
| 30+ | 688.04 грн |
| 60+ | 659.02 грн |
| 120+ | 632.90 грн |
