MF40202V1-1000U-A99 Sunon
| Кількість | Ціна |
|---|---|
| 30+ | 663.47 грн |
| 60+ | 624.51 грн |
| 120+ | 590.71 грн |
| 270+ | 529.73 грн |
| 510+ | 479.58 грн |
Відгуки про товар
Написати відгук
Технічний опис MF40202V1-1000U-A99 Sunon
Category: DC24V Fans, Description: Fan: DC; axial; 24VDC; 40x40x20mm; 15.04m3/h; 25.5dBA; Vapo; 7000rpm, Operating temperature: -10...70°C, Impeller material: thermoplastic, Flammability rating: UL94V-0, Current rating: 32mA, Fan dimensions: 40x40x20mm, Lead length: 0.305m, Insulation class: A, Power consumption: 0.77W, Supply voltage: 24V DC, Static pressure: 5.59mm H2O, Operating voltage: 8...27.6V DC, Fan efficiency: 15.04m3/h, Noise level: 25.5dBA, Wire size: 26AWG, Rotational rate/speed: 7000rpm, Min. insulation resistance: 10MΩ, Additional functions: autorestart, Kind of fan: axial, Kind of Bearing: Vapo, Fan motor: brushless DC, Type of fan: DC, Leads: leads x2, Enclosure material: thermoplastic.
Інші пропозиції MF40202V1-1000U-A99 за ціною від 187.08 грн до 601.28 грн
| Фото | Назва | Виробник | Інформація |
Доступність |
Ціна |
||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
MF40202V1-1000U-A99 | SUNON |
 Category: DC24V FansDescription: Fan: DC; axial; 24VDC; 40x40x20mm; 15.04m3/h; 25.5dBA; Vapo; 7000rpm Operating temperature: -10...70°C Impeller material: thermoplastic Flammability rating: UL94V-0 Current rating: 32mA Fan dimensions: 40x40x20mm Lead length: 0.305m Insulation class: A Power consumption: 0.77W Supply voltage: 24V DC Static pressure: 5.59mm H2O Operating voltage: 8...27.6V DC Fan efficiency: 15.04m3/h Noise level: 25.5dBA Wire size: 26AWG Rotational rate/speed: 7000rpm Min. insulation resistance: 10MΩ Additional functions: autorestart Kind of fan: axial Kind of Bearing: Vapo Fan motor: brushless DC Type of fan: DC Leads: leads x2 Enclosure material: thermoplastic |
на замовлення 5768 шт: термін постачання 14-30 дні (днів) |
|
||||||||||
 |
MF40202V1-1000U-A99 | SUNON |
Description: SUNON - MF40202V1-1000U-A99 - DC FAN, VAPO, 40MM, 7000RPM, 24VDC tariffCode: 0 euEccn: NLR Stromanschluss: 2 Lead Wires rohsCompliant: YES hazardous: false rohsPhthalatesCompliant: YES Art des Lagers: Vapo Bearing Nennleistung: 770mW isCanonical: Y IP-Schutzart: - Luftstrom - m3/min: - Nennstrom: 32mA Außentiefe: 20mm Geräuschentwicklung: 25.5dBA Luftstrom - CFM: 8.9cu.ft/min SVHC: No SVHC (27-Jun-2024) Lüfterrahmen: Square Produktpalette: DC Brushless M Series productTraceability: No Rahmengröße: 40mm usEccn: EAR99 Versorgungsspannung, V DC: 24V Nenndrehzahl: 7000rpm directShipCharge: 25 |
на замовлення 61 шт: термін постачання 21-31 дні (днів) |
|
||||||||||
 |
MF40202V1-1000U-A99 | Sunon Fans |
Description: FAN AXIAL 40X20MM 24VDC WIRE Features: Auto Restart Packaging: Bulk Voltage - Rated: 24VDC Size / Dimension: Square - 40mm L x 40mm H Bearing Type: Vapo-Bearing™ RPM: 7000 RPM Air Flow: 8.9 CFM (0.249m³/min) Width: 20.00mm Weight: 0.064 lb (29.03 g) Operating Temperature: 14 ~ 158°F (-10 ~ 70°C) Termination: 2 Wire Leads Approval Agency: cURus, TUV Fan Type: Tubeaxial Noise: 25.5dB(A) Static Pressure: 0.220 in H2O (55.0 Pa) Part Status: Active Power (Watts): 770 mW |
на замовлення 2917 шт: термін постачання 21-31 дні (днів) |
|
| MF40202V1-1000U-A99 |
|
Виробник: SUNON
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x20mm; 15.04m3/h; 25.5dBA; Vapo; 7000rpm
Operating temperature: -10...70°C
Impeller material: thermoplastic
Flammability rating: UL94V-0
Current rating: 32mA
Fan dimensions: 40x40x20mm
Lead length: 0.305m
Insulation class: A
Power consumption: 0.77W
Supply voltage: 24V DC
Static pressure: 5.59mm H2O
Operating voltage: 8...27.6V DC
Fan efficiency: 15.04m3/h
Noise level: 25.5dBA
Wire size: 26AWG
Rotational rate/speed: 7000rpm
Min. insulation resistance: 10MΩ
Additional functions: autorestart
Kind of fan: axial
Kind of Bearing: Vapo
Fan motor: brushless DC
Type of fan: DC
Leads: leads x2
Enclosure material: thermoplastic
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x20mm; 15.04m3/h; 25.5dBA; Vapo; 7000rpm
Operating temperature: -10...70°C
Impeller material: thermoplastic
Flammability rating: UL94V-0
Current rating: 32mA
Fan dimensions: 40x40x20mm
Lead length: 0.305m
Insulation class: A
Power consumption: 0.77W
Supply voltage: 24V DC
Static pressure: 5.59mm H2O
Operating voltage: 8...27.6V DC
Fan efficiency: 15.04m3/h
Noise level: 25.5dBA
Wire size: 26AWG
Rotational rate/speed: 7000rpm
Min. insulation resistance: 10MΩ
Additional functions: autorestart
Kind of fan: axial
Kind of Bearing: Vapo
Fan motor: brushless DC
Type of fan: DC
Leads: leads x2
Enclosure material: thermoplastic
на замовлення 5768 шт:
термін постачання 14-30 дні (днів)| Кількість | Ціна |
|---|---|
| 2+ | 294.46 грн |
| 50+ | 215.86 грн |
| 100+ | 194.70 грн |
| 200+ | 187.08 грн |
| MF40202V1-1000U-A99 |
|
Виробник: SUNON
Description: SUNON - MF40202V1-1000U-A99 - DC FAN, VAPO, 40MM, 7000RPM, 24VDC
tariffCode: 0
euEccn: NLR
Stromanschluss: 2 Lead Wires
rohsCompliant: YES
hazardous: false
rohsPhthalatesCompliant: YES
Art des Lagers: Vapo Bearing
Nennleistung: 770mW
isCanonical: Y
IP-Schutzart: -
Luftstrom - m3/min: -
Nennstrom: 32mA
Außentiefe: 20mm
Geräuschentwicklung: 25.5dBA
Luftstrom - CFM: 8.9cu.ft/min
SVHC: No SVHC (27-Jun-2024)
Lüfterrahmen: Square
Produktpalette: DC Brushless M Series
productTraceability: No
Rahmengröße: 40mm
usEccn: EAR99
Versorgungsspannung, V DC: 24V
Nenndrehzahl: 7000rpm
directShipCharge: 25
Description: SUNON - MF40202V1-1000U-A99 - DC FAN, VAPO, 40MM, 7000RPM, 24VDC
tariffCode: 0
euEccn: NLR
Stromanschluss: 2 Lead Wires
rohsCompliant: YES
hazardous: false
rohsPhthalatesCompliant: YES
Art des Lagers: Vapo Bearing
Nennleistung: 770mW
isCanonical: Y
IP-Schutzart: -
Luftstrom - m3/min: -
Nennstrom: 32mA
Außentiefe: 20mm
Geräuschentwicklung: 25.5dBA
Luftstrom - CFM: 8.9cu.ft/min
SVHC: No SVHC (27-Jun-2024)
Lüfterrahmen: Square
Produktpalette: DC Brushless M Series
productTraceability: No
Rahmengröße: 40mm
usEccn: EAR99
Versorgungsspannung, V DC: 24V
Nenndrehzahl: 7000rpm
directShipCharge: 25
на замовлення 61 шт:
термін постачання 21-31 дні (днів)| Кількість | Ціна |
|---|---|
| 2+ | 599.76 грн |
| 5+ | 549.71 грн |
| 10+ | 534.94 грн |
| 25+ | 484.54 грн |
| 50+ | 435.32 грн |
| MF40202V1-1000U-A99 |
|
Виробник: Sunon Fans
Description: FAN AXIAL 40X20MM 24VDC WIRE
Features: Auto Restart
Packaging: Bulk
Voltage - Rated: 24VDC
Size / Dimension: Square - 40mm L x 40mm H
Bearing Type: Vapo-Bearing™
RPM: 7000 RPM
Air Flow: 8.9 CFM (0.249m³/min)
Width: 20.00mm
Weight: 0.064 lb (29.03 g)
Operating Temperature: 14 ~ 158°F (-10 ~ 70°C)
Termination: 2 Wire Leads
Approval Agency: cURus, TUV
Fan Type: Tubeaxial
Noise: 25.5dB(A)
Static Pressure: 0.220 in H2O (55.0 Pa)
Part Status: Active
Power (Watts): 770 mW
Description: FAN AXIAL 40X20MM 24VDC WIRE
Features: Auto Restart
Packaging: Bulk
Voltage - Rated: 24VDC
Size / Dimension: Square - 40mm L x 40mm H
Bearing Type: Vapo-Bearing™
RPM: 7000 RPM
Air Flow: 8.9 CFM (0.249m³/min)
Width: 20.00mm
Weight: 0.064 lb (29.03 g)
Operating Temperature: 14 ~ 158°F (-10 ~ 70°C)
Termination: 2 Wire Leads
Approval Agency: cURus, TUV
Fan Type: Tubeaxial
Noise: 25.5dB(A)
Static Pressure: 0.220 in H2O (55.0 Pa)
Part Status: Active
Power (Watts): 770 mW
на замовлення 2917 шт:
термін постачання 21-31 дні (днів)| Кількість | Ціна |
|---|---|
| 1+ | 601.28 грн |
| 10+ | 470.22 грн |
| 25+ | 429.23 грн |
| 50+ | 375.13 грн |
| 200+ | 335.69 грн |
