HA60151V4-1000U-A99 SUNON

Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 60x60x15mm; 21.46m3/h; 14.5dBA; Vapo; 2200rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 4.5...13.8V DC
Fan dimensions: 60x60x15mm
Current rating: 22mA
Fan efficiency: 21.46m3/h
Noise level: 14.5dBA
Kind of Bearing: Vapo
Rotational rate/speed: 2200rpm
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Lead length: 0.29m
Operating temperature: -10...70°C
Additional functions: autorestart
Min. insulation resistance: 10MΩ
Insulation class: A
Fan motor: brushless DC
Flammability rating: UL94V-0
Power consumption: 0.27W
Static pressure: 1.02mm H2O
Current and power consumption tolerance: ±15%
Wire size: 26AWG
на замовлення 1278 шт:
термін постачання 21-30 дні (днів)
Кількість | Ціна |
---|---|
2+ | 286.97 грн |
50+ | 205.16 грн |
100+ | 178.43 грн |
200+ | 169.00 грн |
Відгуки про товар
Написати відгук
Технічний опис HA60151V4-1000U-A99 SUNON
Category: DC12V Fans, Description: Fan: DC; axial; 12VDC; 60x60x15mm; 21.46m3/h; 14.5dBA; Vapo; 2200rpm, Type of fan: DC, Kind of fan: axial, Supply voltage: 12V DC, Operating voltage: 4.5...13.8V DC, Fan dimensions: 60x60x15mm, Current rating: 22mA, Fan efficiency: 21.46m3/h, Noise level: 14.5dBA, Kind of Bearing: Vapo, Rotational rate/speed: 2200rpm, Impeller material: thermoplastic, Enclosure material: thermoplastic, Leads: leads x2, Lead length: 0.29m, Operating temperature: -10...70°C, Additional functions: autorestart, Min. insulation resistance: 10MΩ, Insulation class: A, Fan motor: brushless DC, Flammability rating: UL94V-0, Power consumption: 0.27W, Static pressure: 1.02mm H2O, Current and power consumption tolerance: ±15%, Wire size: 26AWG, кількість в упаковці: 1 шт.
Інші пропозиції HA60151V4-1000U-A99 за ціною від 202.80 грн до 752.49 грн
Фото | Назва | Виробник | Інформація |
Доступність |
Ціна | ||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
![]() |
HA60151V4-1000U-A99 | Виробник : SUNON |
![]() Description: Fan: DC; axial; 12VDC; 60x60x15mm; 21.46m3/h; 14.5dBA; Vapo; 2200rpm Type of fan: DC Kind of fan: axial Supply voltage: 12V DC Operating voltage: 4.5...13.8V DC Fan dimensions: 60x60x15mm Current rating: 22mA Fan efficiency: 21.46m3/h Noise level: 14.5dBA Kind of Bearing: Vapo Rotational rate/speed: 2200rpm Impeller material: thermoplastic Enclosure material: thermoplastic Leads: leads x2 Lead length: 0.29m Operating temperature: -10...70°C Additional functions: autorestart Min. insulation resistance: 10MΩ Insulation class: A Fan motor: brushless DC Flammability rating: UL94V-0 Power consumption: 0.27W Static pressure: 1.02mm H2O Current and power consumption tolerance: ±15% Wire size: 26AWG кількість в упаковці: 1 шт |
на замовлення 1278 шт: термін постачання 14-21 дні (днів) |
|
||||||||||||
![]() |
HA60151V4-1000U-A99 | Виробник : Sunon Fans |
![]() Packaging: Bulk Features: Auto Restart Voltage - Rated: 12VDC Size / Dimension: Square - 60mm L x 60mm H Bearing Type: Vapo-Bearing™ RPM: 2200 RPM Air Flow: 12.7 CFM (0.356m³/min) Width: 15.00mm Weight: 0.077 lb (34.93 g) Termination: 2 Wire Leads Approval Agency: CE, CUR, TUV, UL Fan Type: Tubeaxial Noise: 14.5dB(A) Static Pressure: 0.040 in H2O (10.0 Pa) Part Status: Active Power (Watts): 270 mW |
на замовлення 7229 шт: термін постачання 21-31 дні (днів) |
|
||||||||||||
![]() |
HA60151V4-1000U-A99 | Виробник : Sunon |
![]() |
на замовлення 190 шт: термін постачання 21-30 дні (днів) |
|
||||||||||||
HA60151V4-1000U-A99 | Виробник : Sunon |
![]() |
на замовлення 1731 шт: термін постачання 21-31 дні (днів) |
|
|||||||||||||
HA60151V4-1000U-A99 | Виробник : Sunon |
![]() |
на замовлення 1110 шт: термін постачання 21-31 дні (днів) |
|
|||||||||||||
![]() |
Вентилятор 60x60x15, 12V, (HA60151V4-A99-A) Код товару: 149579
Додати до обраних
Обраний товар
|
Виробник : Sunon |
Корпусні та встановлювальні вироби > Вентилятори та аксесуари Габаритні розміри, mm: 60x60x15 mm Напруга, В: 12 DC Об’єм повітря, м.куб/год.: 21,46 м³/год. Потужність, W: 0,36 Вт Шум, dB: 14,5 дБ Швидкість обертання, об/хв: 2200 об/хв Опис: Підшипник Vapo (магнітна підвіска) |
товару немає в наявності
|
|
