XDS3302 Owon Technology Lilliput Electronics (USA) Inc

Category: Digital Oscilloscopes, Description: Oscilloscope: digital; Ch: 2; 300MHz; 2,5Gsps; 40Mpts; LCD TFT 8", Type of oscilloscope: digital, Number of channels: 2, Band: 300MHz, Sampling: 2,5Gsps, Memory record length: 40Mpts, Kind of display used: LCD TFT 8", Trigger modes: automatic; normal; single, Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232; runt; slope; SPI; timeout; video signal; window, Time base: 1n...1ks/div, Max. input voltage: 300V, Vertical resolution: 8bit, Input coupling: AC, DC, GND, Manufacturer series: XDS, Rise time: ≤1.17ns, Input impedance: 1MΩ/15pF, Input sensitivity: 1mV/div...10V/div, Additional functions: frequency meter, Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART, Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual, Power consumption: 24W, Body dimensions: 340x177x90mm, Related items: XDS-SOFTBAG, Supply voltage: 100...240V AC, Software: LabVIEW, Measurement memory: 100, Connection: RJ45; USB; VGA + AV, Display resolution: 800x600, Touchpad: yes, Connectors for the country: Europe.
