MSCSM120HM083AG Microchip Technology MSCSM120HM083AG-SiC-MOSFET-module-DS00004648.pdf Description: PM-MOSFET-SIC-SP6C
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 4 N-Channel (Full Bridge)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 1.042kW (Tc)
Drain to Source Voltage (Vdss): 1200V (1.2kV)
Current - Continuous Drain (Id) @ 25°C: 251A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 9000pF @ 1000V
Rds On (Max) @ Id, Vgs: 10.4mOhm @ 120A, 20V
Gate Charge (Qg) (Max) @ Vgs: 696nC @ 20V
Vgs(th) (Max) @ Id: 2.8V @ 9mA
Part Status: Active
товар відсутній
MSCSM120HM063AG Microchip Technology MSCSM120HM063AG-SiC-MOSFET-module-DS00004646.pdf Description: PM-MOSFET-SIC-SP6C
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 4 N-Channel (Full Bridge)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 873W (Tc)
Drain to Source Voltage (Vdss): 1200V (1.2kV)
Current - Continuous Drain (Id) @ 25°C: 333A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 12000pF @ 1000V
Rds On (Max) @ Id, Vgs: 7.8mOhm @ 80A, 20V
Gate Charge (Qg) (Max) @ Vgs: 928nC @ 20V
Vgs(th) (Max) @ Id: 2.8V @ 12mA
Part Status: Active
товар відсутній
MSCSM120AM11T3AG Microchip Technology MSCSM120AM11T3AG-SiC-MOSFET-module-DS00004577.pdf Description: PM-MOSFET-SIC-SP3F
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 2 N Channel (Phase Leg)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 1.067kW (Tc)
Drain to Source Voltage (Vdss): 1200V (1.2kV)
Current - Continuous Drain (Id) @ 25°C: 254A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 9060pF @ 1000V
Rds On (Max) @ Id, Vgs: 10.4mOhm @ 120A, 20V
Gate Charge (Qg) (Max) @ Vgs: 696nC @ 20V
Vgs(th) (Max) @ Id: 2.8V @ 9mA
Part Status: Active
товар відсутній
MSCSM70AM07T3AG Microchip Technology MSCSM70AM07T3AG-SiC-MOSFET-module-DS00004606.pdf Description: SIC 2N-CH 700V 353A
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 2 N Channel (Phase Leg)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 988W (Tc)
Drain to Source Voltage (Vdss): 700V
Current - Continuous Drain (Id) @ 25°C: 353A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 13500pF @ 700V
Rds On (Max) @ Id, Vgs: 6.4mOhm @ 120A, 20V
Gate Charge (Qg) (Max) @ Vgs: 645nC @ 20V
Vgs(th) (Max) @ Id: 2.4V @ 12mA
Part Status: Active
на замовлення 6 шт:
термін постачання 21-31 дні (днів)
1+18366.63 грн
MSCSM70AM10T3AG Microchip Technology MSCSM70AM10T3AG-SiC-MOSFET-module-DS00004608.pdf Description: SIC 2N-CH 700V 241A
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 2 N Channel (Phase Leg)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 690W (Tc)
Drain to Source Voltage (Vdss): 700V
Current - Continuous Drain (Id) @ 25°C: 241A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 9000pF @ 700V
Rds On (Max) @ Id, Vgs: 9.5mOhm @ 80A, 20V
Gate Charge (Qg) (Max) @ Vgs: 430nC @ 20V
Vgs(th) (Max) @ Id: 2.4V @ 8mA
Part Status: Active
на замовлення 10 шт:
термін постачання 21-31 дні (днів)
1+13509.95 грн
MSCSM120HM16T3AG Microchip Technology MSCSM120HM16T3AG-SiC-MOSFET-module-DS00004613.pdf Description: PM-MOSFET-SIC-SP3F
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 4 N-Channel (Full Bridge)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 745W (Tc)
Drain to Source Voltage (Vdss): 1200V (1.2kV)
Current - Continuous Drain (Id) @ 25°C: 173A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 6040pF @ 1000V
Rds On (Max) @ Id, Vgs: 16mOhm @ 80A, 20V
Gate Charge (Qg) (Max) @ Vgs: 464nC @ 20V
Vgs(th) (Max) @ Id: 2.8V @ 6mA
Part Status: Active
товар відсутній
MSCSM70AM19T1AG Microchip Technology MSCSM70AM19T1AG-SiC-MOSFET-module-DS00004605.pdf Description: SIC 2N-CH 700V 124A
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 2 N Channel (Phase Leg)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 365W (Tc)
Drain to Source Voltage (Vdss): 700V
Current - Continuous Drain (Id) @ 25°C: 124A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 4500pF @ 700V
Rds On (Max) @ Id, Vgs: 19mOhm @ 40A, 20V
Gate Charge (Qg) (Max) @ Vgs: 215nC @ 20V
Vgs(th) (Max) @ Id: 2.4V @ 4mA
Part Status: Active
на замовлення 10 шт:
термін постачання 21-31 дні (днів)
1+6787.59 грн
MSCSM120AM31T1AG Microchip Technology MSCSM120AM31T1AG-SiC-MOSFET-module-DS00004618.pdf Description: SIC 2N-CH 1200V 89A
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 2 N Channel (Phase Leg)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 395W (Tc)
Drain to Source Voltage (Vdss): 1200V (1.2kV)
Current - Continuous Drain (Id) @ 25°C: 89A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 3020pF @ 1000V
Rds On (Max) @ Id, Vgs: 31mOhm @ 40A, 20V
Gate Charge (Qg) (Max) @ Vgs: 232nC @ 20V
Vgs(th) (Max) @ Id: 2.8V @ 3mA
Part Status: Active
товар відсутній
MSCSM70AM025T6AG Microchip Technology MSCSM70AM025T6AG-SiC-MOSFET-module-DS00004628.pdf Description: PM-MOSFET-SIC-SP6C
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 2 N Channel (Phase Leg)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 1.882kW (Tc)
Drain to Source Voltage (Vdss): 700V
Current - Continuous Drain (Id) @ 25°C: 689A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 27000pF @ 700V
Rds On (Max) @ Id, Vgs: 3.2mOhm @ 240A, 20V
Gate Charge (Qg) (Max) @ Vgs: 1290nC @ 20V
Vgs(th) (Max) @ Id: 2.4V @ 24mA
Part Status: Active
товар відсутній
MSCSM70AM025T6LIAG Microchip Technology MSCSM70AM025T6LIAG-SiC-MOSFET-module-DS00004627.pdf Description: PM-MOSFET-SIC-SP6L1
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 2 N Channel (Phase Leg)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 1.882kW (Tc)
Drain to Source Voltage (Vdss): 700V
Current - Continuous Drain (Id) @ 25°C: 689A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 27000pF @ 700V
Rds On (Max) @ Id, Vgs: 3.2mOhm @ 240A, 20V
Gate Charge (Qg) (Max) @ Vgs: 1290nC @ 20V
Vgs(th) (Max) @ Id: 2.4V @ 24mA
Part Status: Active
товар відсутній
MSCSM120AM03T6LIAG Microchip Technology MSCSM120AM03T6LIAG-SiC-MOSFET-module-DS00004570.pdf Description: PM-MOSFET-SIC-SP6L1
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 2 N Channel (Phase Leg)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 3.215kW (Tc)
Drain to Source Voltage (Vdss): 1200V (1.2kV)
Current - Continuous Drain (Id) @ 25°C: 805A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 30200pF @ 1000V
Rds On (Max) @ Id, Vgs: 3.1mOhm @ 400A, 20V
Gate Charge (Qg) (Max) @ Vgs: 2320nC @ 20V
Vgs(th) (Max) @ Id: 2.8V @ 30mA
Part Status: Active
товар відсутній
MSCSM120HM31T3AG Microchip Technology MSCSM120HM31T3AG-SiC-MOSFET-module-DS00004643.pdf Description: SIC 4N-CH 1200V 89A
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 4 N-Channel (Full Bridge)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 395W (Tc)
Drain to Source Voltage (Vdss): 1200V (1.2kV)
Current - Continuous Drain (Id) @ 25°C: 89A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 3020pF @ 1000V
Rds On (Max) @ Id, Vgs: 31mOhm @ 40A, 20V
Gate Charge (Qg) (Max) @ Vgs: 232nC @ 20V
Vgs(th) (Max) @ Id: 2.8V @ 3mA
Part Status: Active
товар відсутній
MSCSM120AM027T6AG Microchip Technology MSCSM120AM027T6AG-SiC-MOSFET-module-DS00004630.pdf Description: PM-MOSFET-SIC-SP6C
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 2 N Channel (Phase Leg)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 2.97kW (Tc)
Drain to Source Voltage (Vdss): 1200V (1.2kV)
Current - Continuous Drain (Id) @ 25°C: 733A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 27000pF @ 1000V
Rds On (Max) @ Id, Vgs: 3.5mOhm @ 360A, 20V
Gate Charge (Qg) (Max) @ Vgs: 2088nC @ 20V
Vgs(th) (Max) @ Id: 2.8V @ 27mA
Part Status: Active
товар відсутній
MSCSM70HM05AG Microchip Technology MSCSM70HM05AG-SiC-MOSFET-module-DS00004601.pdf Description: PM-MOSFET-SIC-SP6C
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 4 N-Channel (Full Bridge)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 966W (Tc)
Drain to Source Voltage (Vdss): 700V
Current - Continuous Drain (Id) @ 25°C: 349A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 13500pF @ 700V
Rds On (Max) @ Id, Vgs: 6.4mOhm @ 120A, 20V
Gate Charge (Qg) (Max) @ Vgs: 645nC @ 20V
Vgs(th) (Max) @ Id: 2.4V @ 12mA
Part Status: Active
товар відсутній
MSCSM70TAM10TPAG Microchip Technology MSCSM70TAM10TPAG-SiC-MOSFET-module-DS00004626.pdf Description: PM-MOSFET-SIC-SP6P
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 6 N-Channel (Phase Leg)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 674W (Tc)
Drain to Source Voltage (Vdss): 700V
Current - Continuous Drain (Id) @ 25°C: 238A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 9000pF @ 700V
Rds On (Max) @ Id, Vgs: 9.5mOhm @ 80A, 20V
Gate Charge (Qg) (Max) @ Vgs: 430nC @ 20V
Vgs(th) (Max) @ Id: 2.4V @ 8mA
Part Status: Active
товар відсутній
MSCSM120TAM11TPAG Microchip Technology MSCSM120TAM11TPAG-SiC-MOSFET-module-DS00004637.pdf Description: PM-MOSFET-SIC-SP6P
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 6 N-Channel (Phase Leg)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 1.042kW (Tc)
Drain to Source Voltage (Vdss): 1200V (1.2kV)
Current - Continuous Drain (Id) @ 25°C: 251A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 9060pF @ 1000V
Rds On (Max) @ Id, Vgs: 10.4mOhm @ 120A, 20V
Gate Charge (Qg) (Max) @ Vgs: 696nC @ 20V
Vgs(th) (Max) @ Id: 2.8V @ 9mA
Part Status: Active
товар відсутній
DSC6083CI2A-307K000T DSC6083CI2A-307K000T Microchip Technology DSC60XX-Ultra-Small-Ultra-Low-Power-MEMS-Oscillator-DS20005625C.pdf Description: MEMS OSC XO 307.0000KHZ CMOS SMD
Packaging: Tape & Reel (TR)
Package / Case: 4-SMD, No Lead
Size / Dimension: 0.126" L x 0.098" W (3.20mm x 2.50mm)
Mounting Type: Surface Mount
Output: CMOS
Type: XO (Standard)
Operating Temperature: -40°C ~ 85°C
Frequency Stability: ±25ppm
Voltage - Supply: 1.71V ~ 3.63V
Ratings: AEC-Q100
Current - Supply (Max): 1.3mA (Typ)
Height - Seated (Max): 0.035" (0.90mm)
Part Status: Obsolete
Frequency: 307 kHz
Base Resonator: MEMS
товар відсутній
MIC4685-5.0BR TR MIC4685-5.0BR TR Microchip Technology mic4685.pdf Description: IC REG BUCK 5V 3A SPAK-7
Packaging: Tape & Reel (TR)
Package / Case: SPak-7 (7 leads + Tab)
Output Type: Fixed
Mounting Type: Surface Mount
Number of Outputs: 1
Function: Step-Down
Current - Output: 3A
Operating Temperature: -40°C ~ 125°C (TJ)
Output Configuration: Positive
Frequency - Switching: 200kHz
Voltage - Input (Max): 30V
Topology: Buck
Supplier Device Package: S-PAK-7
Synchronous Rectifier: No
Voltage - Input (Min): 4V
Voltage - Output (Min/Fixed): 5V
Part Status: Obsolete
товар відсутній
CDLL4976 Microchip Technology Description: VOLTAGE REGULATOR
Packaging: Bulk
Part Status: Active
товар відсутній
MXPLAD15KP130A Microchip Technology 9522-mplad15kp-datasheet Description: TVS DIODE 130VWM 209VC PLAD
товар відсутній
MXPLAD15KP130Ae3 Microchip Technology 9522-mplad15kp-datasheet Description: TVS DIODE 130VWM 209VC PLAD
товар відсутній
MXLPLAD15KP130Ae3 Microchip Technology 9522-mplad15kp-datasheet Description: TVS DIODE 130VWM 209VC PLAD
товар відсутній
MPLAD15KP130A/TR MPLAD15KP130A/TR Microchip Technology 9522-mplad15kp-datasheet Description: TVS DIODE 130VWM 209VC PLAD
Packaging: Tape & Reel (TR)
Package / Case: Nonstandard SMD
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -55°C ~ 150°C (TJ)
Applications: General Purpose
Current - Peak Pulse (10/1000µs): 71A
Voltage - Reverse Standoff (Typ): 130V
Supplier Device Package: PLAD
Unidirectional Channels: 1
Voltage - Breakdown (Min): 144V
Voltage - Clamping (Max) @ Ipp: 209V
Power - Peak Pulse: 15000W (15kW)
Power Line Protection: No
Grade: Military
Qualification: MIL-PRF-19500
товар відсутній
MAPLAD15KP130A MAPLAD15KP130A Microchip Technology 9522-mplad15kp-datasheet Description: TVS DIODE 130VWM 209VC PLAD
Packaging: Bulk
Package / Case: Nonstandard SMD
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -55°C ~ 150°C (TJ)
Applications: General Purpose
Current - Peak Pulse (10/1000µs): 71A
Voltage - Reverse Standoff (Typ): 130V
Supplier Device Package: PLAD
Unidirectional Channels: 1
Voltage - Breakdown (Min): 144V
Voltage - Clamping (Max) @ Ipp: 209V
Power - Peak Pulse: 15000W (15kW)
Power Line Protection: No
Grade: Military
Qualification: MIL-PRF-19500
товар відсутній
MA15KP130Ae3 MA15KP130Ae3 Microchip Technology 9460-rf01011-m15kp-rev-e Description: TVS DIODE 130VWM 209VC DO204AR
Packaging: Bulk
Package / Case: DO-204AR, Axial
Mounting Type: Through Hole
Type: Zener
Operating Temperature: -65°C ~ 150°C (TJ)
Applications: General Purpose
Current - Peak Pulse (10/1000µs): 72A
Voltage - Reverse Standoff (Typ): 130V
Supplier Device Package: DO-204AR
Unidirectional Channels: 1
Voltage - Breakdown (Min): 144V
Voltage - Clamping (Max) @ Ipp: 209V
Power - Peak Pulse: 15000W (15kW)
Power Line Protection: No
Grade: Military
Qualification: MIL-PRF-19500
товар відсутній
MAPLAD15KP130Ae3 MAPLAD15KP130Ae3 Microchip Technology 9522-mplad15kp-datasheet Description: TVS DIODE 130VWM 209VC PLAD
Packaging: Bulk
Package / Case: Nonstandard SMD
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -55°C ~ 150°C (TJ)
Applications: General Purpose
Current - Peak Pulse (10/1000µs): 71A
Voltage - Reverse Standoff (Typ): 130V
Supplier Device Package: PLAD
Unidirectional Channels: 1
Voltage - Breakdown (Min): 144V
Voltage - Clamping (Max) @ Ipp: 209V
Power - Peak Pulse: 15000W (15kW)
Power Line Protection: No
Grade: Military
Qualification: MIL-PRF-19500
товар відсутній
MXLPLAD15KP130A Microchip Technology 9522-mplad15kp-datasheet Description: TVS DIODE 130VWM 209VC PLAD
товар відсутній
M15KP130Ae3 M15KP130Ae3 Microchip Technology 9460-rf01011-m15kp-rev-e-datasheet Description: TVS DIODE 130VWM 209VC DO204AR
Packaging: Bulk
Package / Case: DO-204AR, Axial
Mounting Type: Through Hole
Type: Zener
Operating Temperature: -65°C ~ 150°C (TJ)
Applications: General Purpose
Current - Peak Pulse (10/1000µs): 72A
Voltage - Reverse Standoff (Typ): 130V
Supplier Device Package: DO-204AR
Unidirectional Channels: 1
Voltage - Breakdown (Min): 144V
Voltage - Clamping (Max) @ Ipp: 209V
Power - Peak Pulse: 15000W (15kW)
Power Line Protection: No
Grade: Military
Qualification: MIL-PRF-19500
товар відсутній
MA15KP130A MA15KP130A Microchip Technology 9460-rf01011-m15kp-rev-e Description: TVS DIODE 130VWM 209VC DO204AR
Packaging: Bulk
Package / Case: DO-204AR, Axial
Mounting Type: Through Hole
Type: Zener
Operating Temperature: -65°C ~ 150°C (TJ)
Applications: General Purpose
Current - Peak Pulse (10/1000µs): 72A
Voltage - Reverse Standoff (Typ): 130V
Supplier Device Package: DO-204AR
Unidirectional Channels: 1
Voltage - Breakdown (Min): 144V
Voltage - Clamping (Max) @ Ipp: 209V
Power - Peak Pulse: 15000W (15kW)
Power Line Protection: No
Grade: Military
Qualification: MIL-PRF-19500
товар відсутній
AT87F52-24PI AT87F52-24PI Microchip Technology AT87F52.pdf Description: IC MCU 8BIT 8KB FLASH 40DIP
товар відсутній
11AA040-I/S16K Microchip Technology 22067J.pdf Description: IC EEPROM 4KBIT SGL WIRE DIE
Packaging: Tape & Reel (TR)
Package / Case: Die
Mounting Type: Surface Mount
Memory Size: 4Kbit
Memory Type: Non-Volatile
Operating Temperature: -40°C ~ 85°C (TA)
Voltage - Supply: 1.8V ~ 5.5V
Technology: EEPROM
Clock Frequency: 100 kHz
Memory Format: EEPROM
Supplier Device Package: Die
Part Status: Active
Write Cycle Time - Word, Page: 5ms
Memory Interface: Single Wire
Memory Organization: 512 x 8
DigiKey Programmable: Not Verified
товар відсутній
11AA040-I/WF16K Microchip Technology 22067J.pdf Description: IC EEPROM 4KBIT SGL WIRE DIE
Packaging: Tray
Package / Case: Die
Mounting Type: Surface Mount
Memory Size: 4Kbit
Memory Type: Non-Volatile
Operating Temperature: -40°C ~ 85°C (TA)
Voltage - Supply: 1.8V ~ 5.5V
Technology: EEPROM
Clock Frequency: 100 kHz
Memory Format: EEPROM
Supplier Device Package: Die
Part Status: Active
Write Cycle Time - Word, Page: 5ms
Memory Interface: Single Wire
Memory Organization: 512 x 8
DigiKey Programmable: Not Verified
товар відсутній
78160GNP Microchip Technology Description: RF MOSFET
Packaging: Bulk
товар відсутній
78161GNP Microchip Technology Description: RF MOSFET
Packaging: Bulk
товар відсутній
SAMA7G54-V/4HB SAMA7G54-V/4HB Microchip Technology SAMA7G5-Series-Data-Sheet-DS60001765.pdf Description: IC MPU SAMA7G5 1GHZ 343TFBGA
Packaging: Tray
Package / Case: 343-TFBGA
Mounting Type: Surface Mount
Speed: 1GHz
Operating Temperature: -40°C ~ 105°C (TJ)
Core Processor: ARM® Cortex®-A7
Voltage - I/O: 3.3V, 5V
Supplier Device Package: 343-TFBGA (14x14)
Ethernet: 10/100Mbps (1), 10/100/1000Mbps (1)
USB: USB 2.0 PHY (3), USB Type-C (2)
Number of Cores/Bus Width: 1 Core, 32-Bit
Co-Processors/DSP: Multimedia; NEON™ MPE
RAM Controllers: DDR2, DDR3, DDR3L, LPDDR2, LPDDR3
Graphics Acceleration: No
Display & Interface Controllers: LCD
Security Features: ARM TZ, Cryptography, 3DES, AES, SHA1, SHA-256, SHA-384, SHA-512
Part Status: Active
Additional Interfaces: EBI, I2C, SPI
на замовлення 783 шт:
термін постачання 21-31 дні (днів)
1+898.44 грн
25+ 793.22 грн
100+ 718.19 грн
DSA612RI1A-01V0VAO Microchip Technology Description: IC CLOCK GENERATOR 6VFLGA
Packaging: Tube
Package / Case: 6-VFLGA
Mounting Type: Surface Mount
Output: LVCMOS
Frequency - Max: 100MHz
Type: Clock Generator
Operating Temperature: -40°C ~ 85°C (TA)
Voltage - Supply: 1.71V ~ 3.63V
Ratio - Input:Output: 0:2
Differential - Input:Output: No/No
Supplier Device Package: 6-VFLGA (2.5x2)
PLL: Yes
Divider/Multiplier: Yes/No
Part Status: Active
Number of Circuits: 1
DigiKey Programmable: Not Verified
товар відсутній
JANTX1N4245 JANTX1N4245 Microchip Technology 123513-lds-0191-datasheet Description: DIODE GEN PURP 200V 1A AXIAL
товар відсутній
JANTX1N3646 Microchip Technology 10953-lds-0266-datasheet Description: DIODE GP 1.75KV 250MA AXIAL
товар відсутній
JANTX1N3612 JANTX1N3612 Microchip Technology 123512-lds-0190-datasheet Description: DIODE GEN PURP 400V 1A AXIAL
Packaging: Bulk
Package / Case: A, Axial
Mounting Type: Through Hole
Speed: Standard Recovery >500ns, > 200mA (Io)
Technology: Standard
Current - Average Rectified (Io): 1A
Supplier Device Package: A, Axial
Operating Temperature - Junction: -65°C ~ 175°C
Part Status: Active
Voltage - DC Reverse (Vr) (Max): 400 V
Voltage - Forward (Vf) (Max) @ If: 1.1 V @ 1 A
Current - Reverse Leakage @ Vr: 1 µA @ 400 V
товар відсутній
JANTXV1N5533D-1 JANTXV1N5533D-1 Microchip Technology 123956-lds-0037-1-datasheet Description: DIODE ZENER 13V 500MW DO35
товар відсутній
VCC6-119-178M018970 Microchip Technology VCC6.pdf Description: DIFFERENTIAL XO +3.3 VDC +/-5% L
товар відсутній
JANTXV1N5772 JANTXV1N5772 Microchip Technology 10048-msc1013-datasheet Description: TVS DIODE 10CFLATPACK
Packaging: Bulk
Package / Case: 10-CFlatPack
Mounting Type: Surface Mount
Type: Steering (Rail to Rail)
Operating Temperature: -65°C ~ 150°C (TJ)
Applications: Ethernet
Supplier Device Package: 10-CFlatPack
Unidirectional Channels: 8
Power Line Protection: No
Part Status: Active
товар відсутній
1N5772 Microchip Technology 10048-msc1013-datasheet Description: TVS DIODE 10CFLATPACK
Packaging: Bulk
Package / Case: 10-CFlatPack
Mounting Type: Surface Mount
Type: Steering (Rail to Rail)
Operating Temperature: -65°C ~ 150°C (TJ)
Applications: Ethernet
Supplier Device Package: 10-CFlatPack
Unidirectional Channels: 8
Power Line Protection: No
Part Status: Discontinued at Digi-Key
товар відсутній
JANTX1N5772 JANTX1N5772 Microchip Technology Description: TVS DIODE 10CFLATPACK
Packaging: Bulk
Package / Case: 10-CFlatPack
Mounting Type: Surface Mount
Type: Steering (Rail to Rail)
Operating Temperature: -65°C ~ 150°C (TJ)
Applications: Ethernet
Supplier Device Package: 10-CFlatPack
Unidirectional Channels: 8
Power Line Protection: No
Part Status: Active
товар відсутній
1N5774 Microchip Technology 10049-msc1014-datasheet Description: TVS DIODE 14FLATPACK
Packaging: Bulk
Package / Case: 14-Flatpack
Mounting Type: Surface Mount
Type: Steering (Rail to Rail)
Operating Temperature: -65°C ~ 150°C (TJ)
Applications: Ethernet
Supplier Device Package: 14-Flatpack
Unidirectional Channels: 8
Power Line Protection: No
Part Status: Active
товар відсутній
1N5768 Microchip Technology 122687-lds-0078-pdf Description: TVS DIODE 10CFLATPACK
Packaging: Bulk
Package / Case: 10-CFlatPack
Mounting Type: Surface Mount
Type: Steering (Rail to Rail)
Operating Temperature: -65°C ~ 150°C (TJ)
Applications: Ethernet
Supplier Device Package: 10-CFlatPack
Unidirectional Channels: 8
Power Line Protection: No
Part Status: Active
товар відсутній
1N5770 Microchip Technology 10047-msc1012-pdf Description: TVS DIODE 10CFLATPACK
Packaging: Bulk
Package / Case: 10-CFlatPack
Mounting Type: Surface Mount
Type: Steering (Rail to Rail)
Operating Temperature: -65°C ~ 150°C (TJ)
Applications: Ethernet
Supplier Device Package: 10-CFlatPack
Unidirectional Channels: 8
Power Line Protection: No
Part Status: Active
товар відсутній
JANTXV1N5774 Microchip Technology 10049-msc1014-datasheet Description: TVS DIODE 14CFLATPACK
Packaging: Bulk
Package / Case: 14-CFlatPack
Mounting Type: Surface Mount
Type: Steering (Rail to Rail)
Operating Temperature: -65°C ~ 150°C (TJ)
Applications: Ethernet
Supplier Device Package: 14-CFlatPack
Unidirectional Channels: 8
Power Line Protection: No
Part Status: Active
товар відсутній
JAN1N5768 Microchip Technology Description: DIODE GEN PURP 300MA 10CFLATPACK
Packaging: Bulk
Package / Case: 10-CFlatPack
Mounting Type: Surface Mount
Speed: Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr): 40 ns
Technology: Standard
Capacitance @ Vr, F: 4pF @ 0V, 1MHz
Current - Average Rectified (Io): 300mA
Supplier Device Package: 10-CFlatPack
Operating Temperature - Junction: -65°C ~ 150°C
Part Status: Active
Voltage - Forward (Vf) (Max) @ If: 1.5 V @ 500 mA
Current - Reverse Leakage @ Vr: 100 nA @ 40 V
товар відсутній
JAN1N3042BUR-1 JAN1N3042BUR-1 Microchip Technology 5787-1n3016bur-datasheet Description: DIODE ZENER 82V 1W DO213AB
товар відсутній
R21130 Microchip Technology Description: STD RECTIFIER
товар відсутній
EV72J15A EV72J15A Microchip Technology EV72J15A.pdf Description: PIC16F17146 CURIOSITY NANO EVALU
Packaging: Box
Mounting Type: Fixed
Type: MCU 8-Bit
Contents: Board(s)
Core Processor: PIC
Utilized IC / Part: PIC16F17146
Platform: Curiosity Nano
товар відсутній
EV40E67A Microchip Technology EV40E67A.pdf Description: SAM9X60-CURIOSITY
товар відсутній
EV12U44A EV12U44A Microchip Technology EV12U44A.pdf Description: PIC32CM LS00 CURIOSITY PRO EVALU
Packaging: Box
Mounting Type: Fixed
Type: MCU 32-Bit
Contents: Board(s)
Core Processor: ARM® Cortex®-M23
Board Type: Evaluation Platform
Utilized IC / Part: PIC32CM LS00
Platform: PIC32CM LS00 Curiosity Pro
Part Status: Active
на замовлення 19 шт:
термін постачання 21-31 дні (днів)
1+5913.97 грн
EV76R77A EV76R77A Microchip Technology EV76R77A.pdf Description: PIC32CM LS60 CURIOSITY PRO EVALU
Packaging: Box
Mounting Type: Fixed
Type: MCU 32-Bit
Contents: Board(s)
Core Processor: ARM® Cortex®-M23
Board Type: Evaluation Platform
Utilized IC / Part: PIC32CM LS60
Platform: PIC32CM LS60 Curiosity Pro
Part Status: Active
на замовлення 18 шт:
термін постачання 21-31 дні (днів)
1+5913.97 грн
EV80P12A EV80P12A Microchip Technology EV80P12A.pdf Description: PIC32CM LE00 CURIOSITY PRO EVALU
Packaging: Box
Mounting Type: Fixed
Type: MCU 32-Bit
Contents: Board(s)
Core Processor: ARM® Cortex®-M23
Board Type: Evaluation Platform
Utilized IC / Part: PIC32CM LE00
Platform: PIC32CM LE00 Curiosity Pro
Part Status: Active
на замовлення 19 шт:
термін постачання 21-31 дні (днів)
1+5913.97 грн
MCP6234-E/STVAO MCP6234-E/STVAO Microchip Technology 20001881G%20MCP6231-20%20uA%20300%20kHz%20Rail-to-Rail%20Op%20Amp.pdf Description: IC OPAMP GP 4 CIRCUIT 14TSSOP
товар відсутній
MCP6234T-E/STVAO MCP6234T-E/STVAO Microchip Technology 20001881G%20MCP6231-20%20uA%20300%20kHz%20Rail-to-Rail%20Op%20Amp.pdf Description: IC OPAMP GP 4 CIRCUIT 14TSSOP
товар відсутній
KSZ8695X KSZ8695X Microchip Technology MCRLS03365-1.pdf?t.download=true&u=5oefqw Description: IC 10/100 INTEG SWITCH 208PQFP
Packaging: Bulk
Package / Case: 208-BFQFP
Mounting Type: Surface Mount
Type: 10/100 Integrated Switch
Applications: Port Switch/Network Interface
Supplier Device Package: 208-PQFP (28x28)
Part Status: Active
на замовлення 1813 шт:
термін постачання 21-31 дні (днів)
26+790.3 грн
Мінімальне замовлення: 26
KSZ8563RNXV-TR KSZ8563RNXV-TR Microchip Technology KSZ8563R-Data-Sheet-DS00002418.pdf Description: IC 3-PORT ETHERNET SWITCH
Packaging: Tape & Reel (TR)
Package / Case: 64-VFQFN Exposed Pad
Function: Switch
Interface: I²C, MII, RGMII, RMII, SPI
Operating Temperature: -40°C ~ 105°C
Voltage - Supply: 3.3V
Protocol: Ethernet
Standards: IEEE 802.3, 10/100 Base-T PHY
Supplier Device Package: 64-VQFN (8x8)
Part Status: Active
DigiKey Programmable: Not Verified
товар відсутній
MSCSM120HM083AG MSCSM120HM083AG-SiC-MOSFET-module-DS00004648.pdf
Виробник: Microchip Technology
Description: PM-MOSFET-SIC-SP6C
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 4 N-Channel (Full Bridge)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 1.042kW (Tc)
Drain to Source Voltage (Vdss): 1200V (1.2kV)
Current - Continuous Drain (Id) @ 25°C: 251A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 9000pF @ 1000V
Rds On (Max) @ Id, Vgs: 10.4mOhm @ 120A, 20V
Gate Charge (Qg) (Max) @ Vgs: 696nC @ 20V
Vgs(th) (Max) @ Id: 2.8V @ 9mA
Part Status: Active
товар відсутній
MSCSM120HM063AG MSCSM120HM063AG-SiC-MOSFET-module-DS00004646.pdf
Виробник: Microchip Technology
Description: PM-MOSFET-SIC-SP6C
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 4 N-Channel (Full Bridge)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 873W (Tc)
Drain to Source Voltage (Vdss): 1200V (1.2kV)
Current - Continuous Drain (Id) @ 25°C: 333A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 12000pF @ 1000V
Rds On (Max) @ Id, Vgs: 7.8mOhm @ 80A, 20V
Gate Charge (Qg) (Max) @ Vgs: 928nC @ 20V
Vgs(th) (Max) @ Id: 2.8V @ 12mA
Part Status: Active
товар відсутній
MSCSM120AM11T3AG MSCSM120AM11T3AG-SiC-MOSFET-module-DS00004577.pdf
Виробник: Microchip Technology
Description: PM-MOSFET-SIC-SP3F
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 2 N Channel (Phase Leg)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 1.067kW (Tc)
Drain to Source Voltage (Vdss): 1200V (1.2kV)
Current - Continuous Drain (Id) @ 25°C: 254A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 9060pF @ 1000V
Rds On (Max) @ Id, Vgs: 10.4mOhm @ 120A, 20V
Gate Charge (Qg) (Max) @ Vgs: 696nC @ 20V
Vgs(th) (Max) @ Id: 2.8V @ 9mA
Part Status: Active
товар відсутній
MSCSM70AM07T3AG MSCSM70AM07T3AG-SiC-MOSFET-module-DS00004606.pdf
Виробник: Microchip Technology
Description: SIC 2N-CH 700V 353A
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 2 N Channel (Phase Leg)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 988W (Tc)
Drain to Source Voltage (Vdss): 700V
Current - Continuous Drain (Id) @ 25°C: 353A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 13500pF @ 700V
Rds On (Max) @ Id, Vgs: 6.4mOhm @ 120A, 20V
Gate Charge (Qg) (Max) @ Vgs: 645nC @ 20V
Vgs(th) (Max) @ Id: 2.4V @ 12mA
Part Status: Active
на замовлення 6 шт:
термін постачання 21-31 дні (днів)
Кількість Ціна без ПДВ
1+18366.63 грн
MSCSM70AM10T3AG MSCSM70AM10T3AG-SiC-MOSFET-module-DS00004608.pdf
Виробник: Microchip Technology
Description: SIC 2N-CH 700V 241A
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 2 N Channel (Phase Leg)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 690W (Tc)
Drain to Source Voltage (Vdss): 700V
Current - Continuous Drain (Id) @ 25°C: 241A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 9000pF @ 700V
Rds On (Max) @ Id, Vgs: 9.5mOhm @ 80A, 20V
Gate Charge (Qg) (Max) @ Vgs: 430nC @ 20V
Vgs(th) (Max) @ Id: 2.4V @ 8mA
Part Status: Active
на замовлення 10 шт:
термін постачання 21-31 дні (днів)
Кількість Ціна без ПДВ
1+13509.95 грн
MSCSM120HM16T3AG MSCSM120HM16T3AG-SiC-MOSFET-module-DS00004613.pdf
Виробник: Microchip Technology
Description: PM-MOSFET-SIC-SP3F
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 4 N-Channel (Full Bridge)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 745W (Tc)
Drain to Source Voltage (Vdss): 1200V (1.2kV)
Current - Continuous Drain (Id) @ 25°C: 173A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 6040pF @ 1000V
Rds On (Max) @ Id, Vgs: 16mOhm @ 80A, 20V
Gate Charge (Qg) (Max) @ Vgs: 464nC @ 20V
Vgs(th) (Max) @ Id: 2.8V @ 6mA
Part Status: Active
товар відсутній
MSCSM70AM19T1AG MSCSM70AM19T1AG-SiC-MOSFET-module-DS00004605.pdf
Виробник: Microchip Technology
Description: SIC 2N-CH 700V 124A
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 2 N Channel (Phase Leg)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 365W (Tc)
Drain to Source Voltage (Vdss): 700V
Current - Continuous Drain (Id) @ 25°C: 124A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 4500pF @ 700V
Rds On (Max) @ Id, Vgs: 19mOhm @ 40A, 20V
Gate Charge (Qg) (Max) @ Vgs: 215nC @ 20V
Vgs(th) (Max) @ Id: 2.4V @ 4mA
Part Status: Active
на замовлення 10 шт:
термін постачання 21-31 дні (днів)
Кількість Ціна без ПДВ
1+6787.59 грн
MSCSM120AM31T1AG MSCSM120AM31T1AG-SiC-MOSFET-module-DS00004618.pdf
Виробник: Microchip Technology
Description: SIC 2N-CH 1200V 89A
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 2 N Channel (Phase Leg)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 395W (Tc)
Drain to Source Voltage (Vdss): 1200V (1.2kV)
Current - Continuous Drain (Id) @ 25°C: 89A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 3020pF @ 1000V
Rds On (Max) @ Id, Vgs: 31mOhm @ 40A, 20V
Gate Charge (Qg) (Max) @ Vgs: 232nC @ 20V
Vgs(th) (Max) @ Id: 2.8V @ 3mA
Part Status: Active
товар відсутній
MSCSM70AM025T6AG MSCSM70AM025T6AG-SiC-MOSFET-module-DS00004628.pdf
Виробник: Microchip Technology
Description: PM-MOSFET-SIC-SP6C
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 2 N Channel (Phase Leg)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 1.882kW (Tc)
Drain to Source Voltage (Vdss): 700V
Current - Continuous Drain (Id) @ 25°C: 689A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 27000pF @ 700V
Rds On (Max) @ Id, Vgs: 3.2mOhm @ 240A, 20V
Gate Charge (Qg) (Max) @ Vgs: 1290nC @ 20V
Vgs(th) (Max) @ Id: 2.4V @ 24mA
Part Status: Active
товар відсутній
MSCSM70AM025T6LIAG MSCSM70AM025T6LIAG-SiC-MOSFET-module-DS00004627.pdf
Виробник: Microchip Technology
Description: PM-MOSFET-SIC-SP6L1
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 2 N Channel (Phase Leg)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 1.882kW (Tc)
Drain to Source Voltage (Vdss): 700V
Current - Continuous Drain (Id) @ 25°C: 689A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 27000pF @ 700V
Rds On (Max) @ Id, Vgs: 3.2mOhm @ 240A, 20V
Gate Charge (Qg) (Max) @ Vgs: 1290nC @ 20V
Vgs(th) (Max) @ Id: 2.4V @ 24mA
Part Status: Active
товар відсутній
MSCSM120AM03T6LIAG MSCSM120AM03T6LIAG-SiC-MOSFET-module-DS00004570.pdf
Виробник: Microchip Technology
Description: PM-MOSFET-SIC-SP6L1
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 2 N Channel (Phase Leg)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 3.215kW (Tc)
Drain to Source Voltage (Vdss): 1200V (1.2kV)
Current - Continuous Drain (Id) @ 25°C: 805A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 30200pF @ 1000V
Rds On (Max) @ Id, Vgs: 3.1mOhm @ 400A, 20V
Gate Charge (Qg) (Max) @ Vgs: 2320nC @ 20V
Vgs(th) (Max) @ Id: 2.8V @ 30mA
Part Status: Active
товар відсутній
MSCSM120HM31T3AG MSCSM120HM31T3AG-SiC-MOSFET-module-DS00004643.pdf
Виробник: Microchip Technology
Description: SIC 4N-CH 1200V 89A
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 4 N-Channel (Full Bridge)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 395W (Tc)
Drain to Source Voltage (Vdss): 1200V (1.2kV)
Current - Continuous Drain (Id) @ 25°C: 89A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 3020pF @ 1000V
Rds On (Max) @ Id, Vgs: 31mOhm @ 40A, 20V
Gate Charge (Qg) (Max) @ Vgs: 232nC @ 20V
Vgs(th) (Max) @ Id: 2.8V @ 3mA
Part Status: Active
товар відсутній
MSCSM120AM027T6AG MSCSM120AM027T6AG-SiC-MOSFET-module-DS00004630.pdf
Виробник: Microchip Technology
Description: PM-MOSFET-SIC-SP6C
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 2 N Channel (Phase Leg)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 2.97kW (Tc)
Drain to Source Voltage (Vdss): 1200V (1.2kV)
Current - Continuous Drain (Id) @ 25°C: 733A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 27000pF @ 1000V
Rds On (Max) @ Id, Vgs: 3.5mOhm @ 360A, 20V
Gate Charge (Qg) (Max) @ Vgs: 2088nC @ 20V
Vgs(th) (Max) @ Id: 2.8V @ 27mA
Part Status: Active
товар відсутній
MSCSM70HM05AG MSCSM70HM05AG-SiC-MOSFET-module-DS00004601.pdf
Виробник: Microchip Technology
Description: PM-MOSFET-SIC-SP6C
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 4 N-Channel (Full Bridge)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 966W (Tc)
Drain to Source Voltage (Vdss): 700V
Current - Continuous Drain (Id) @ 25°C: 349A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 13500pF @ 700V
Rds On (Max) @ Id, Vgs: 6.4mOhm @ 120A, 20V
Gate Charge (Qg) (Max) @ Vgs: 645nC @ 20V
Vgs(th) (Max) @ Id: 2.4V @ 12mA
Part Status: Active
товар відсутній
MSCSM70TAM10TPAG MSCSM70TAM10TPAG-SiC-MOSFET-module-DS00004626.pdf
Виробник: Microchip Technology
Description: PM-MOSFET-SIC-SP6P
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 6 N-Channel (Phase Leg)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 674W (Tc)
Drain to Source Voltage (Vdss): 700V
Current - Continuous Drain (Id) @ 25°C: 238A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 9000pF @ 700V
Rds On (Max) @ Id, Vgs: 9.5mOhm @ 80A, 20V
Gate Charge (Qg) (Max) @ Vgs: 430nC @ 20V
Vgs(th) (Max) @ Id: 2.4V @ 8mA
Part Status: Active
товар відсутній
MSCSM120TAM11TPAG MSCSM120TAM11TPAG-SiC-MOSFET-module-DS00004637.pdf
Виробник: Microchip Technology
Description: PM-MOSFET-SIC-SP6P
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Configuration: 6 N-Channel (Phase Leg)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 1.042kW (Tc)
Drain to Source Voltage (Vdss): 1200V (1.2kV)
Current - Continuous Drain (Id) @ 25°C: 251A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 9060pF @ 1000V
Rds On (Max) @ Id, Vgs: 10.4mOhm @ 120A, 20V
Gate Charge (Qg) (Max) @ Vgs: 696nC @ 20V
Vgs(th) (Max) @ Id: 2.8V @ 9mA
Part Status: Active
товар відсутній
DSC6083CI2A-307K000T DSC60XX-Ultra-Small-Ultra-Low-Power-MEMS-Oscillator-DS20005625C.pdf
DSC6083CI2A-307K000T
Виробник: Microchip Technology
Description: MEMS OSC XO 307.0000KHZ CMOS SMD
Packaging: Tape & Reel (TR)
Package / Case: 4-SMD, No Lead
Size / Dimension: 0.126" L x 0.098" W (3.20mm x 2.50mm)
Mounting Type: Surface Mount
Output: CMOS
Type: XO (Standard)
Operating Temperature: -40°C ~ 85°C
Frequency Stability: ±25ppm
Voltage - Supply: 1.71V ~ 3.63V
Ratings: AEC-Q100
Current - Supply (Max): 1.3mA (Typ)
Height - Seated (Max): 0.035" (0.90mm)
Part Status: Obsolete
Frequency: 307 kHz
Base Resonator: MEMS
товар відсутній
MIC4685-5.0BR TR mic4685.pdf
MIC4685-5.0BR TR
Виробник: Microchip Technology
Description: IC REG BUCK 5V 3A SPAK-7
Packaging: Tape & Reel (TR)
Package / Case: SPak-7 (7 leads + Tab)
Output Type: Fixed
Mounting Type: Surface Mount
Number of Outputs: 1
Function: Step-Down
Current - Output: 3A
Operating Temperature: -40°C ~ 125°C (TJ)
Output Configuration: Positive
Frequency - Switching: 200kHz
Voltage - Input (Max): 30V
Topology: Buck
Supplier Device Package: S-PAK-7
Synchronous Rectifier: No
Voltage - Input (Min): 4V
Voltage - Output (Min/Fixed): 5V
Part Status: Obsolete
товар відсутній
CDLL4976
Виробник: Microchip Technology
Description: VOLTAGE REGULATOR
Packaging: Bulk
Part Status: Active
товар відсутній
MXPLAD15KP130A 9522-mplad15kp-datasheet
Виробник: Microchip Technology
Description: TVS DIODE 130VWM 209VC PLAD
товар відсутній
MXPLAD15KP130Ae3 9522-mplad15kp-datasheet
Виробник: Microchip Technology
Description: TVS DIODE 130VWM 209VC PLAD
товар відсутній
MXLPLAD15KP130Ae3 9522-mplad15kp-datasheet
Виробник: Microchip Technology
Description: TVS DIODE 130VWM 209VC PLAD
товар відсутній
MPLAD15KP130A/TR 9522-mplad15kp-datasheet
MPLAD15KP130A/TR
Виробник: Microchip Technology
Description: TVS DIODE 130VWM 209VC PLAD
Packaging: Tape & Reel (TR)
Package / Case: Nonstandard SMD
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -55°C ~ 150°C (TJ)
Applications: General Purpose
Current - Peak Pulse (10/1000µs): 71A
Voltage - Reverse Standoff (Typ): 130V
Supplier Device Package: PLAD
Unidirectional Channels: 1
Voltage - Breakdown (Min): 144V
Voltage - Clamping (Max) @ Ipp: 209V
Power - Peak Pulse: 15000W (15kW)
Power Line Protection: No
Grade: Military
Qualification: MIL-PRF-19500
товар відсутній
MAPLAD15KP130A 9522-mplad15kp-datasheet
MAPLAD15KP130A
Виробник: Microchip Technology
Description: TVS DIODE 130VWM 209VC PLAD
Packaging: Bulk
Package / Case: Nonstandard SMD
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -55°C ~ 150°C (TJ)
Applications: General Purpose
Current - Peak Pulse (10/1000µs): 71A
Voltage - Reverse Standoff (Typ): 130V
Supplier Device Package: PLAD
Unidirectional Channels: 1
Voltage - Breakdown (Min): 144V
Voltage - Clamping (Max) @ Ipp: 209V
Power - Peak Pulse: 15000W (15kW)
Power Line Protection: No
Grade: Military
Qualification: MIL-PRF-19500
товар відсутній
MA15KP130Ae3 9460-rf01011-m15kp-rev-e
MA15KP130Ae3
Виробник: Microchip Technology
Description: TVS DIODE 130VWM 209VC DO204AR
Packaging: Bulk
Package / Case: DO-204AR, Axial
Mounting Type: Through Hole
Type: Zener
Operating Temperature: -65°C ~ 150°C (TJ)
Applications: General Purpose
Current - Peak Pulse (10/1000µs): 72A
Voltage - Reverse Standoff (Typ): 130V
Supplier Device Package: DO-204AR
Unidirectional Channels: 1
Voltage - Breakdown (Min): 144V
Voltage - Clamping (Max) @ Ipp: 209V
Power - Peak Pulse: 15000W (15kW)
Power Line Protection: No
Grade: Military
Qualification: MIL-PRF-19500
товар відсутній
MAPLAD15KP130Ae3 9522-mplad15kp-datasheet
MAPLAD15KP130Ae3
Виробник: Microchip Technology
Description: TVS DIODE 130VWM 209VC PLAD
Packaging: Bulk
Package / Case: Nonstandard SMD
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -55°C ~ 150°C (TJ)
Applications: General Purpose
Current - Peak Pulse (10/1000µs): 71A
Voltage - Reverse Standoff (Typ): 130V
Supplier Device Package: PLAD
Unidirectional Channels: 1
Voltage - Breakdown (Min): 144V
Voltage - Clamping (Max) @ Ipp: 209V
Power - Peak Pulse: 15000W (15kW)
Power Line Protection: No
Grade: Military
Qualification: MIL-PRF-19500
товар відсутній
MXLPLAD15KP130A 9522-mplad15kp-datasheet
Виробник: Microchip Technology
Description: TVS DIODE 130VWM 209VC PLAD
товар відсутній
M15KP130Ae3 9460-rf01011-m15kp-rev-e-datasheet
M15KP130Ae3
Виробник: Microchip Technology
Description: TVS DIODE 130VWM 209VC DO204AR
Packaging: Bulk
Package / Case: DO-204AR, Axial
Mounting Type: Through Hole
Type: Zener
Operating Temperature: -65°C ~ 150°C (TJ)
Applications: General Purpose
Current - Peak Pulse (10/1000µs): 72A
Voltage - Reverse Standoff (Typ): 130V
Supplier Device Package: DO-204AR
Unidirectional Channels: 1
Voltage - Breakdown (Min): 144V
Voltage - Clamping (Max) @ Ipp: 209V
Power - Peak Pulse: 15000W (15kW)
Power Line Protection: No
Grade: Military
Qualification: MIL-PRF-19500
товар відсутній
MA15KP130A 9460-rf01011-m15kp-rev-e
MA15KP130A
Виробник: Microchip Technology
Description: TVS DIODE 130VWM 209VC DO204AR
Packaging: Bulk
Package / Case: DO-204AR, Axial
Mounting Type: Through Hole
Type: Zener
Operating Temperature: -65°C ~ 150°C (TJ)
Applications: General Purpose
Current - Peak Pulse (10/1000µs): 72A
Voltage - Reverse Standoff (Typ): 130V
Supplier Device Package: DO-204AR
Unidirectional Channels: 1
Voltage - Breakdown (Min): 144V
Voltage - Clamping (Max) @ Ipp: 209V
Power - Peak Pulse: 15000W (15kW)
Power Line Protection: No
Grade: Military
Qualification: MIL-PRF-19500
товар відсутній
AT87F52-24PI AT87F52.pdf
AT87F52-24PI
Виробник: Microchip Technology
Description: IC MCU 8BIT 8KB FLASH 40DIP
товар відсутній
11AA040-I/S16K 22067J.pdf
Виробник: Microchip Technology
Description: IC EEPROM 4KBIT SGL WIRE DIE
Packaging: Tape & Reel (TR)
Package / Case: Die
Mounting Type: Surface Mount
Memory Size: 4Kbit
Memory Type: Non-Volatile
Operating Temperature: -40°C ~ 85°C (TA)
Voltage - Supply: 1.8V ~ 5.5V
Technology: EEPROM
Clock Frequency: 100 kHz
Memory Format: EEPROM
Supplier Device Package: Die
Part Status: Active
Write Cycle Time - Word, Page: 5ms
Memory Interface: Single Wire
Memory Organization: 512 x 8
DigiKey Programmable: Not Verified
товар відсутній
11AA040-I/WF16K 22067J.pdf
Виробник: Microchip Technology
Description: IC EEPROM 4KBIT SGL WIRE DIE
Packaging: Tray
Package / Case: Die
Mounting Type: Surface Mount
Memory Size: 4Kbit
Memory Type: Non-Volatile
Operating Temperature: -40°C ~ 85°C (TA)
Voltage - Supply: 1.8V ~ 5.5V
Technology: EEPROM
Clock Frequency: 100 kHz
Memory Format: EEPROM
Supplier Device Package: Die
Part Status: Active
Write Cycle Time - Word, Page: 5ms
Memory Interface: Single Wire
Memory Organization: 512 x 8
DigiKey Programmable: Not Verified
товар відсутній
78160GNP
Виробник: Microchip Technology
Description: RF MOSFET
Packaging: Bulk
товар відсутній
78161GNP
Виробник: Microchip Technology
Description: RF MOSFET
Packaging: Bulk
товар відсутній
SAMA7G54-V/4HB SAMA7G5-Series-Data-Sheet-DS60001765.pdf
SAMA7G54-V/4HB
Виробник: Microchip Technology
Description: IC MPU SAMA7G5 1GHZ 343TFBGA
Packaging: Tray
Package / Case: 343-TFBGA
Mounting Type: Surface Mount
Speed: 1GHz
Operating Temperature: -40°C ~ 105°C (TJ)
Core Processor: ARM® Cortex®-A7
Voltage - I/O: 3.3V, 5V
Supplier Device Package: 343-TFBGA (14x14)
Ethernet: 10/100Mbps (1), 10/100/1000Mbps (1)
USB: USB 2.0 PHY (3), USB Type-C (2)
Number of Cores/Bus Width: 1 Core, 32-Bit
Co-Processors/DSP: Multimedia; NEON™ MPE
RAM Controllers: DDR2, DDR3, DDR3L, LPDDR2, LPDDR3
Graphics Acceleration: No
Display & Interface Controllers: LCD
Security Features: ARM TZ, Cryptography, 3DES, AES, SHA1, SHA-256, SHA-384, SHA-512
Part Status: Active
Additional Interfaces: EBI, I2C, SPI
на замовлення 783 шт:
термін постачання 21-31 дні (днів)
Кількість Ціна без ПДВ
1+898.44 грн
25+ 793.22 грн
100+ 718.19 грн
DSA612RI1A-01V0VAO
Виробник: Microchip Technology
Description: IC CLOCK GENERATOR 6VFLGA
Packaging: Tube
Package / Case: 6-VFLGA
Mounting Type: Surface Mount
Output: LVCMOS
Frequency - Max: 100MHz
Type: Clock Generator
Operating Temperature: -40°C ~ 85°C (TA)
Voltage - Supply: 1.71V ~ 3.63V
Ratio - Input:Output: 0:2
Differential - Input:Output: No/No
Supplier Device Package: 6-VFLGA (2.5x2)
PLL: Yes
Divider/Multiplier: Yes/No
Part Status: Active
Number of Circuits: 1
DigiKey Programmable: Not Verified
товар відсутній
JANTX1N4245 123513-lds-0191-datasheet
JANTX1N4245
Виробник: Microchip Technology
Description: DIODE GEN PURP 200V 1A AXIAL
товар відсутній
JANTX1N3646 10953-lds-0266-datasheet
Виробник: Microchip Technology
Description: DIODE GP 1.75KV 250MA AXIAL
товар відсутній
JANTX1N3612 123512-lds-0190-datasheet
JANTX1N3612
Виробник: Microchip Technology
Description: DIODE GEN PURP 400V 1A AXIAL
Packaging: Bulk
Package / Case: A, Axial
Mounting Type: Through Hole
Speed: Standard Recovery >500ns, > 200mA (Io)
Technology: Standard
Current - Average Rectified (Io): 1A
Supplier Device Package: A, Axial
Operating Temperature - Junction: -65°C ~ 175°C
Part Status: Active
Voltage - DC Reverse (Vr) (Max): 400 V
Voltage - Forward (Vf) (Max) @ If: 1.1 V @ 1 A
Current - Reverse Leakage @ Vr: 1 µA @ 400 V
товар відсутній
JANTXV1N5533D-1 123956-lds-0037-1-datasheet
JANTXV1N5533D-1
Виробник: Microchip Technology
Description: DIODE ZENER 13V 500MW DO35
товар відсутній
VCC6-119-178M018970 VCC6.pdf
Виробник: Microchip Technology
Description: DIFFERENTIAL XO +3.3 VDC +/-5% L
товар відсутній
JANTXV1N5772 10048-msc1013-datasheet
JANTXV1N5772
Виробник: Microchip Technology
Description: TVS DIODE 10CFLATPACK
Packaging: Bulk
Package / Case: 10-CFlatPack
Mounting Type: Surface Mount
Type: Steering (Rail to Rail)
Operating Temperature: -65°C ~ 150°C (TJ)
Applications: Ethernet
Supplier Device Package: 10-CFlatPack
Unidirectional Channels: 8
Power Line Protection: No
Part Status: Active
товар відсутній
1N5772 10048-msc1013-datasheet
Виробник: Microchip Technology
Description: TVS DIODE 10CFLATPACK
Packaging: Bulk
Package / Case: 10-CFlatPack
Mounting Type: Surface Mount
Type: Steering (Rail to Rail)
Operating Temperature: -65°C ~ 150°C (TJ)
Applications: Ethernet
Supplier Device Package: 10-CFlatPack
Unidirectional Channels: 8
Power Line Protection: No
Part Status: Discontinued at Digi-Key
товар відсутній
JANTX1N5772
JANTX1N5772
Виробник: Microchip Technology
Description: TVS DIODE 10CFLATPACK
Packaging: Bulk
Package / Case: 10-CFlatPack
Mounting Type: Surface Mount
Type: Steering (Rail to Rail)
Operating Temperature: -65°C ~ 150°C (TJ)
Applications: Ethernet
Supplier Device Package: 10-CFlatPack
Unidirectional Channels: 8
Power Line Protection: No
Part Status: Active
товар відсутній
1N5774 10049-msc1014-datasheet
Виробник: Microchip Technology
Description: TVS DIODE 14FLATPACK
Packaging: Bulk
Package / Case: 14-Flatpack
Mounting Type: Surface Mount
Type: Steering (Rail to Rail)
Operating Temperature: -65°C ~ 150°C (TJ)
Applications: Ethernet
Supplier Device Package: 14-Flatpack
Unidirectional Channels: 8
Power Line Protection: No
Part Status: Active
товар відсутній
1N5768 122687-lds-0078-pdf
Виробник: Microchip Technology
Description: TVS DIODE 10CFLATPACK
Packaging: Bulk
Package / Case: 10-CFlatPack
Mounting Type: Surface Mount
Type: Steering (Rail to Rail)
Operating Temperature: -65°C ~ 150°C (TJ)
Applications: Ethernet
Supplier Device Package: 10-CFlatPack
Unidirectional Channels: 8
Power Line Protection: No
Part Status: Active
товар відсутній
1N5770 10047-msc1012-pdf
Виробник: Microchip Technology
Description: TVS DIODE 10CFLATPACK
Packaging: Bulk
Package / Case: 10-CFlatPack
Mounting Type: Surface Mount
Type: Steering (Rail to Rail)
Operating Temperature: -65°C ~ 150°C (TJ)
Applications: Ethernet
Supplier Device Package: 10-CFlatPack
Unidirectional Channels: 8
Power Line Protection: No
Part Status: Active
товар відсутній
JANTXV1N5774 10049-msc1014-datasheet
Виробник: Microchip Technology
Description: TVS DIODE 14CFLATPACK
Packaging: Bulk
Package / Case: 14-CFlatPack
Mounting Type: Surface Mount
Type: Steering (Rail to Rail)
Operating Temperature: -65°C ~ 150°C (TJ)
Applications: Ethernet
Supplier Device Package: 14-CFlatPack
Unidirectional Channels: 8
Power Line Protection: No
Part Status: Active
товар відсутній
JAN1N5768
Виробник: Microchip Technology
Description: DIODE GEN PURP 300MA 10CFLATPACK
Packaging: Bulk
Package / Case: 10-CFlatPack
Mounting Type: Surface Mount
Speed: Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr): 40 ns
Technology: Standard
Capacitance @ Vr, F: 4pF @ 0V, 1MHz
Current - Average Rectified (Io): 300mA
Supplier Device Package: 10-CFlatPack
Operating Temperature - Junction: -65°C ~ 150°C
Part Status: Active
Voltage - Forward (Vf) (Max) @ If: 1.5 V @ 500 mA
Current - Reverse Leakage @ Vr: 100 nA @ 40 V
товар відсутній
JAN1N3042BUR-1 5787-1n3016bur-datasheet
JAN1N3042BUR-1
Виробник: Microchip Technology
Description: DIODE ZENER 82V 1W DO213AB
товар відсутній
R21130
Виробник: Microchip Technology
Description: STD RECTIFIER
товар відсутній
EV72J15A EV72J15A.pdf
EV72J15A
Виробник: Microchip Technology
Description: PIC16F17146 CURIOSITY NANO EVALU
Packaging: Box
Mounting Type: Fixed
Type: MCU 8-Bit
Contents: Board(s)
Core Processor: PIC
Utilized IC / Part: PIC16F17146
Platform: Curiosity Nano
товар відсутній
EV40E67A EV40E67A.pdf
Виробник: Microchip Technology
Description: SAM9X60-CURIOSITY
товар відсутній
EV12U44A EV12U44A.pdf
EV12U44A
Виробник: Microchip Technology
Description: PIC32CM LS00 CURIOSITY PRO EVALU
Packaging: Box
Mounting Type: Fixed
Type: MCU 32-Bit
Contents: Board(s)
Core Processor: ARM® Cortex®-M23
Board Type: Evaluation Platform
Utilized IC / Part: PIC32CM LS00
Platform: PIC32CM LS00 Curiosity Pro
Part Status: Active
на замовлення 19 шт:
термін постачання 21-31 дні (днів)
Кількість Ціна без ПДВ
1+5913.97 грн
EV76R77A EV76R77A.pdf
EV76R77A
Виробник: Microchip Technology
Description: PIC32CM LS60 CURIOSITY PRO EVALU
Packaging: Box
Mounting Type: Fixed
Type: MCU 32-Bit
Contents: Board(s)
Core Processor: ARM® Cortex®-M23
Board Type: Evaluation Platform
Utilized IC / Part: PIC32CM LS60
Platform: PIC32CM LS60 Curiosity Pro
Part Status: Active
на замовлення 18 шт:
термін постачання 21-31 дні (днів)
Кількість Ціна без ПДВ
1+5913.97 грн
EV80P12A EV80P12A.pdf
EV80P12A
Виробник: Microchip Technology
Description: PIC32CM LE00 CURIOSITY PRO EVALU
Packaging: Box
Mounting Type: Fixed
Type: MCU 32-Bit
Contents: Board(s)
Core Processor: ARM® Cortex®-M23
Board Type: Evaluation Platform
Utilized IC / Part: PIC32CM LE00
Platform: PIC32CM LE00 Curiosity Pro
Part Status: Active
на замовлення 19 шт:
термін постачання 21-31 дні (днів)
Кількість Ціна без ПДВ
1+5913.97 грн
MCP6234-E/STVAO 20001881G%20MCP6231-20%20uA%20300%20kHz%20Rail-to-Rail%20Op%20Amp.pdf
MCP6234-E/STVAO
Виробник: Microchip Technology
Description: IC OPAMP GP 4 CIRCUIT 14TSSOP
товар відсутній
MCP6234T-E/STVAO 20001881G%20MCP6231-20%20uA%20300%20kHz%20Rail-to-Rail%20Op%20Amp.pdf
MCP6234T-E/STVAO
Виробник: Microchip Technology
Description: IC OPAMP GP 4 CIRCUIT 14TSSOP
товар відсутній
KSZ8695X MCRLS03365-1.pdf?t.download=true&u=5oefqw
KSZ8695X
Виробник: Microchip Technology
Description: IC 10/100 INTEG SWITCH 208PQFP
Packaging: Bulk
Package / Case: 208-BFQFP
Mounting Type: Surface Mount
Type: 10/100 Integrated Switch
Applications: Port Switch/Network Interface
Supplier Device Package: 208-PQFP (28x28)
Part Status: Active
на замовлення 1813 шт:
термін постачання 21-31 дні (днів)
Кількість Ціна без ПДВ
26+790.3 грн
Мінімальне замовлення: 26
KSZ8563RNXV-TR KSZ8563R-Data-Sheet-DS00002418.pdf
KSZ8563RNXV-TR
Виробник: Microchip Technology
Description: IC 3-PORT ETHERNET SWITCH
Packaging: Tape & Reel (TR)
Package / Case: 64-VFQFN Exposed Pad
Function: Switch
Interface: I²C, MII, RGMII, RMII, SPI
Operating Temperature: -40°C ~ 105°C
Voltage - Supply: 3.3V
Protocol: Ethernet
Standards: IEEE 802.3, 10/100 Base-T PHY
Supplier Device Package: 64-VQFN (8x8)
Part Status: Active
DigiKey Programmable: Not Verified
товар відсутній
Обрати Сторінку:   [  << Попередня Сторінка ]  1 559 1118 1562 1563 1564 1565 1566 1567 1568 1569 1570 1571 1572 1677 2236 2795 3354 3913 4472 5031 5590 5599  [ Наступна Сторінка >> ]
