1-87232-0 TE Connectivity AMP Connectors

Description: CONN HEADER R/A 10POS 2.54MM, Packaging: Tray, Contact Length - Mating: 0.318" (8.08mm), Insulation Material: Polyamide (PA), Nylon, Glass Filled, Shrouding: Unshrouded, Insulation Height: 0.138" (3.50mm), Contact Length - Post: 0.110" (2.79mm), Contact Shape: Square, Part Status: Active, Contact Finish - Post: Gold, Contact Finish Thickness - Mating: 30.0µin (0.76µm), Contact Finish - Mating: Gold, Pitch - Mating: 0.100" (2.54mm), Insulation Color: Black, Contact Material: Phosphor Bronze, Material Flammability Rating: UL94 V-0, Termination: Solder, Number of Positions Loaded: All, Fastening Type: Push-Pull, Contact Type: Male Pin, Operating Temperature: -65°C ~ 105°C, Style: Board to Board or Cable, Number of Rows: 1, Number of Positions: 10, Mounting Type: Through Hole, Right Angle, Current Rating (Amps): 3A, Connector Type: Header.
