643698-6 TE Connectivity AMP Connectors

Description: CONN HEADER VERT 7POS 2.54MM, Operating Temperature: -55°C ~ 105°C, Contact Length - Mating: 0.295" (7.49mm), Insulation Material: Thermoplastic, Overall Contact Length: 0.535" (13.59mm), Shrouding: Shrouded - 1 Wall, Insulation Height: 0.305" (7.75mm), Contact Length - Post: 0.140" (3.56mm), Contact Shape: Square, Contact Finish - Post: Tin, Contact Finish - Mating: Tin, Pitch - Mating: 0.100" (2.54mm), Insulation Color: Natural, Contact Material: Copper Alloy, Style: Board to Cable/Wire, Number of Rows: 1, Number of Positions: 7, Mounting Type: Through Hole, Current Rating (Amps): Varies by Wire Gauge, Voltage Rating: 250VAC, Connector Type: Header, Packaging: Bulk, Material Flammability Rating: UL94 V-0, Termination: Solder, Number of Positions Loaded: 6, Fastening Type: Friction Lock, Contact Type: Male Pin.
