Продукція > INFINEON TECHNOLOGIES > Всі товари виробника INFINEON TECHNOLOGIES (129582) > Сторінка 168 з 2160

Виробник: Infineon Technologies
Description: MOSFET P-CH 12V 10A 8TSSOP

Виробник: Infineon Technologies
Description: MOSFET 2N-CH 30V 4.6A 8TSSOP

Виробник: Infineon Technologies
Description: MOSFET N-CH 30V 13.6A 8SO
Packaging: Cut Tape (CT)
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 13.6A (Ta)
Rds On (Max) @ Id, Vgs: 12.5mOhm @ 10A, 4.5V
Power Dissipation (Max): 2.5W (Ta)
Vgs(th) (Max) @ Id: 1V @ 250µA
Supplier Device Package: 8-SO
Part Status: Obsolete
Drive Voltage (Max Rds On, Min Rds On): 4.5V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 30 V
Gate Charge (Qg) (Max) @ Vgs: 14 nC @ 5 V
Input Capacitance (Ciss) (Max) @ Vds: 1010 pF @ 15 V

Виробник: Infineon Technologies
Description: MOSFET N-CH 100V 8.3A 8SO
Packaging: Cut Tape (CT)
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 8.3A (Ta)
Rds On (Max) @ Id, Vgs: 18mOhm @ 8.3A, 10V
Power Dissipation (Max): 2.5W (Ta)
Vgs(th) (Max) @ Id: 4.9V @ 100µA
Supplier Device Package: 8-SO
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 100 V
Gate Charge (Qg) (Max) @ Vgs: 39 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 1640 pF @ 25 V

Виробник: Infineon Technologies
Description: MOSFET N-CH 80V 10A 8SO
Packaging: Cut Tape (CT)
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 10A (Ta)
Rds On (Max) @ Id, Vgs: 13.4mOhm @ 10A, 10V
Power Dissipation (Max): 2.5W (Ta)
Vgs(th) (Max) @ Id: 4.9V @ 100µA
Supplier Device Package: 8-SO
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 80 V
Gate Charge (Qg) (Max) @ Vgs: 41 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 1620 pF @ 25 V

Виробник: Infineon Technologies
Description: MOSFET N-CH 60V 12A 8SO
Packaging: Cut Tape (CT)
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 12A (Ta)
Rds On (Max) @ Id, Vgs: 9.4mOhm @ 12A, 10V
Power Dissipation (Max): 2.5W (Ta)
Vgs(th) (Max) @ Id: 4.9V @ 100µA
Supplier Device Package: 8-SO
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 60 V
Gate Charge (Qg) (Max) @ Vgs: 39 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 1560 pF @ 25 V
Voltage Coupled to Gate Charge (Qg) (Max) @ Vgs: 10
Voltage Coupled to Input Capacitance (Ciss) (Max) @ Vds: 25

Виробник: Infineon Technologies
Description: MOSFET 2N-CH 30V 7.6A/11A 8SO
Packaging: Cut Tape (CT)
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Mounting Type: Surface Mount
Configuration: 2 N-Channel (Half Bridge)
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
Power - Max: 1.4W, 2W
Drain to Source Voltage (Vdss): 30V
Current - Continuous Drain (Id) @ 25°C: 7.6A, 11A
Input Capacitance (Ciss) (Max) @ Vds: 910pF @ 15V
Rds On (Max) @ Id, Vgs: 16.2mOhm @ 7.6A, 10V
Gate Charge (Qg) (Max) @ Vgs: 11nC @ 4.5V
FET Feature: Logic Level Gate
Vgs(th) (Max) @ Id: 2.25V @ 25µA
Supplier Device Package: 8-SO
Part Status: Not For New Designs

Виробник: Infineon Technologies
Description: MOSFET 2N-CH 30V 9.1A/11A 8SO
Packaging: Cut Tape (CT)
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Mounting Type: Surface Mount
Configuration: 2 N-Channel (Dual)
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
Power - Max: 2W
Drain to Source Voltage (Vdss): 30V
Current - Continuous Drain (Id) @ 25°C: 9.1A, 11A
Input Capacitance (Ciss) (Max) @ Vds: 850pF @ 15V
Rds On (Max) @ Id, Vgs: 16.4mOhm @ 9.1A, 10V
Gate Charge (Qg) (Max) @ Vgs: 10nC @ 4.5V
FET Feature: Logic Level Gate
Vgs(th) (Max) @ Id: 2.35V @ 25µA
Supplier Device Package: 8-SO
Part Status: Active

Виробник: Infineon Technologies
Description: MOSFET N-CH 100V 80A D2PAK
Packaging: Cut Tape (CT)
Package / Case: TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 80A (Tc)
Rds On (Max) @ Id, Vgs: 15mOhm @ 45A, 10V
Power Dissipation (Max): 260W (Tc)
Vgs(th) (Max) @ Id: 4V @ 250µA
Supplier Device Package: D2PAK
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 100 V
Gate Charge (Qg) (Max) @ Vgs: 120 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 3830 pF @ 25 V

Виробник: Infineon Technologies
Description: MOSFET P-CH 100V 14A D2PAK
Packaging: Cut Tape (CT)
Package / Case: TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: P-Channel
Current - Continuous Drain (Id) @ 25°C: 14A (Tc)
Rds On (Max) @ Id, Vgs: 200mOhm @ 8.4A, 10V
Power Dissipation (Max): 3.8W (Ta), 79W (Tc)
Vgs(th) (Max) @ Id: 4V @ 250µA
Supplier Device Package: D2PAK
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 100 V
Gate Charge (Qg) (Max) @ Vgs: 58 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 760 pF @ 25 V

Виробник: Infineon Technologies
Description: MOSFET P-CH 100V 23A D2PAK
Packaging: Cut Tape (CT)
Package / Case: TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: P-Channel
Current - Continuous Drain (Id) @ 25°C: 23A (Tc)
Rds On (Max) @ Id, Vgs: 117mOhm @ 14A, 10V
Power Dissipation (Max): 3.1W (Ta), 110W (Tc)
Vgs(th) (Max) @ Id: 4V @ 250µA
Supplier Device Package: D2PAK
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 100 V
Gate Charge (Qg) (Max) @ Vgs: 110 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 1450 pF @ 25 V
Voltage Coupled to Gate Charge (Qg) (Max) @ Vgs: 10
Voltage Coupled to Input Capacitance (Ciss) (Max) @ Vds: 25

Виробник: Infineon Technologies
Description: MOSFET N-CH 55V 2.8A SOT223
Packaging: Cut Tape (CT)
Package / Case: TO-261-4, TO-261AA
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 2.8A (Ta)
Rds On (Max) @ Id, Vgs: 75mOhm @ 2.8A, 10V
Power Dissipation (Max): 1W (Ta)
Vgs(th) (Max) @ Id: 4V @ 250µA
Supplier Device Package: SOT-223
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 55 V
Gate Charge (Qg) (Max) @ Vgs: 18.3 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 400 pF @ 25 V

Виробник: Infineon Technologies
Description: MOSFET N-CH 55V 5.1A SOT223
Packaging: Cut Tape (CT)
Package / Case: TO-261-4, TO-261AA
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 5.1A (Ta)
Rds On (Max) @ Id, Vgs: 57.5mOhm @ 3.1A, 10V
Power Dissipation (Max): 1W (Ta)
Vgs(th) (Max) @ Id: 4V @ 250µA
Supplier Device Package: SOT-223
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 55 V
Gate Charge (Qg) (Max) @ Vgs: 14 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 340 pF @ 25 V
Voltage Coupled to Gate Charge (Qg) (Max) @ Vgs: 10
Voltage Coupled to Input Capacitance (Ciss) (Max) @ Vds: 25

Виробник: Infineon Technologies
Description: MOSFET N-CH 150V 2.6A SOT223
Packaging: Cut Tape (CT)
Package / Case: TO-261-4, TO-261AA
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 2.6A (Ta)
Rds On (Max) @ Id, Vgs: 185mOhm @ 1.6A, 10V
Power Dissipation (Max): 2.8W (Ta)
Vgs(th) (Max) @ Id: 5V @ 250µA
Supplier Device Package: SOT-223
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±30V
Drain to Source Voltage (Vdss): 150 V
Gate Charge (Qg) (Max) @ Vgs: 19 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 420 pF @ 25 V

Виробник: Infineon Technologies
Description: MOSFET N-CH 150V 24A DPAK
Packaging: Cut Tape (CT)
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 24A (Tc)
Rds On (Max) @ Id, Vgs: 95mOhm @ 14A, 10V
Power Dissipation (Max): 140W (Tc)
Vgs(th) (Max) @ Id: 5V @ 250µA
Supplier Device Package: TO-252AA (DPAK)
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±30V
Drain to Source Voltage (Vdss): 150 V
Gate Charge (Qg) (Max) @ Vgs: 45 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 890 pF @ 25 V

Виробник: Infineon Technologies
Description: MOSFET N-CH 100V 32A DPAK
Packaging: Cut Tape (CT)
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 32A (Tc)
Rds On (Max) @ Id, Vgs: 44mOhm @ 16A, 10V
Power Dissipation (Max): 130W (Tc)
Vgs(th) (Max) @ Id: 4V @ 250µA
Supplier Device Package: TO-252AA (DPAK)
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 100 V
Gate Charge (Qg) (Max) @ Vgs: 71 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 1960 pF @ 25 V

Виробник: Infineon Technologies
Description: MOSFET N-CH 100V 42A DPAK
Packaging: Cut Tape (CT)
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 42A (Tc)
Rds On (Max) @ Id, Vgs: 18mOhm @ 33A, 10V
Power Dissipation (Max): 140W (Tc)
Vgs(th) (Max) @ Id: 4V @ 250µA
Supplier Device Package: TO-252AA (DPAK)
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 100 V
Gate Charge (Qg) (Max) @ Vgs: 100 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 2930 pF @ 25 V
Voltage Coupled to Gate Charge (Qg) (Max) @ Vgs: 10
Voltage Coupled to Input Capacitance (Ciss) (Max) @ Vds: 25

Виробник: Infineon Technologies
Description: MOSFET P-CH 150V 13A DPAK
Packaging: Cut Tape (CT)
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: P-Channel
Current - Continuous Drain (Id) @ 25°C: 13A (Tc)
Rds On (Max) @ Id, Vgs: 295mOhm @ 6.6A, 10V
Power Dissipation (Max): 110W (Tc)
Vgs(th) (Max) @ Id: 4V @ 250µA
Supplier Device Package: TO-252AA (DPAK)
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 150 V
Gate Charge (Qg) (Max) @ Vgs: 66 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 860 pF @ 25 V

Виробник: Infineon Technologies
Description: MOSFET N-CH 75V 120A D2PAK
Packaging: Cut Tape (CT)
Package / Case: TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 120A (Tc)
Rds On (Max) @ Id, Vgs: 6.3mOhm @ 75A, 10V
Power Dissipation (Max): 200W (Tc)
Vgs(th) (Max) @ Id: 4V @ 150µA
Supplier Device Package: D2PAK
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 75 V
Gate Charge (Qg) (Max) @ Vgs: 180 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 5150 pF @ 50 V

Виробник: Infineon Technologies
Description: MOSFET N-CH 200V 43A D2PAK
Packaging: Cut Tape (CT)
Package / Case: TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 43A (Tc)
Rds On (Max) @ Id, Vgs: 54mOhm @ 26A, 10V
Power Dissipation (Max): 3.8W (Ta), 300W (Tc)
Vgs(th) (Max) @ Id: 5V @ 250µA
Supplier Device Package: D2PAK
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 200 V
Gate Charge (Qg) (Max) @ Vgs: 91 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 2900 pF @ 25 V

Виробник: Infineon Technologies
Description: MOSFET N-CH 200V 62A D2PAK
Packaging: Cut Tape (CT)
Package / Case: TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 62A (Tc)
Rds On (Max) @ Id, Vgs: 26mOhm @ 46A, 10V
Power Dissipation (Max): 330W (Tc)
Vgs(th) (Max) @ Id: 5V @ 250µA
Supplier Device Package: D2PAK
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±30V
Drain to Source Voltage (Vdss): 200 V
Gate Charge (Qg) (Max) @ Vgs: 98 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 4600 pF @ 25 V

Виробник: Infineon Technologies
Description: MOSFET N-CH 100V 130A D2PAK
Packaging: Cut Tape (CT)
Package / Case: TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 130A (Tc)
Rds On (Max) @ Id, Vgs: 7mOhm @ 75A, 10V
Power Dissipation (Max): 300W (Tc)
Vgs(th) (Max) @ Id: 4V @ 250µA
Supplier Device Package: D2PAK
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 100 V
Gate Charge (Qg) (Max) @ Vgs: 250 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 7670 pF @ 50 V

Виробник: Infineon Technologies
Description: MOSFET N-CH 100V 73A D2PAK
Packaging: Cut Tape (CT)
Package / Case: TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 73A (Tc)
Rds On (Max) @ Id, Vgs: 14mOhm @ 44A, 10V
Power Dissipation (Max): 190W (Tc)
Vgs(th) (Max) @ Id: 4V @ 100µA
Supplier Device Package: D2PAK
Part Status: Not For New Designs
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 100 V
Gate Charge (Qg) (Max) @ Vgs: 140 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 3550 pF @ 50 V

Виробник: Infineon Technologies
Description: MOSFET N-CH 150V 51A D2PAK
Packaging: Cut Tape (CT)
Package / Case: TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 51A (Tc)
Rds On (Max) @ Id, Vgs: 32mOhm @ 36A, 10V
Power Dissipation (Max): 3.8W (Ta), 230W (Tc)
Vgs(th) (Max) @ Id: 5V @ 250µA
Supplier Device Package: D2PAK
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±30V
Drain to Source Voltage (Vdss): 150 V
Gate Charge (Qg) (Max) @ Vgs: 89 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 2770 pF @ 25 V

Виробник: Infineon Technologies
Description: MOSFET N-CH 55V 29A D2PAK
Packaging: Cut Tape (CT)
Package / Case: TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 29A (Tc)
Rds On (Max) @ Id, Vgs: 40mOhm @ 16A, 10V
Power Dissipation (Max): 3.8W (Ta), 68W (Tc)
Vgs(th) (Max) @ Id: 4V @ 250µA
Supplier Device Package: D2PAK
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 55 V
Gate Charge (Qg) (Max) @ Vgs: 34 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 700 pF @ 25 V

Виробник: Infineon Technologies
Description: MOSFET N-CH 60V 48A D2PAK
Packaging: Cut Tape (CT)
Package / Case: TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 48A (Tc)
Rds On (Max) @ Id, Vgs: 23mOhm @ 29A, 10V
Power Dissipation (Max): 110W (Tc)
Vgs(th) (Max) @ Id: 4V @ 250µA
Supplier Device Package: D2PAK
Part Status: Not For New Designs
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 60 V
Gate Charge (Qg) (Max) @ Vgs: 60 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 1360 pF @ 25 V

Виробник: Infineon Technologies
Description: MOSFET N-CH 55V 51A D2PAK
Packaging: Cut Tape (CT)
Package / Case: TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 51A (Tc)
Rds On (Max) @ Id, Vgs: 13.9mOhm @ 31A, 10V
Power Dissipation (Max): 80W (Tc)
Vgs(th) (Max) @ Id: 4V @ 250µA
Supplier Device Package: D2PAK
Part Status: Not For New Designs
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 55 V
Gate Charge (Qg) (Max) @ Vgs: 43 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 1420 pF @ 25 V

Виробник: Infineon Technologies
Description: IGBT 600V 28A 167W D2PAK
Packaging: Cut Tape (CT)
Package / Case: TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Input Type: Standard
Vce(on) (Max) @ Vge, Ic: 2.2V @ 15V, 8A
Supplier Device Package: D2PAK
IGBT Type: NPT
Td (on/off) @ 25°C: 23ns/140ns
Switching Energy: 160µJ (on), 160µJ (off)
Test Condition: 400V, 8A, 50Ohm, 15V
Gate Charge: 29 nC
Current - Collector (Ic) (Max): 28 A
Voltage - Collector Emitter Breakdown (Max): 600 V
Current - Collector Pulsed (Icm): 34 A
Power - Max: 167 W

Виробник: Infineon Technologies
Description: MOSFET N-CH 55V 75A D2PAK
Packaging: Cut Tape (CT)
Package / Case: TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 75A (Tc)
Rds On (Max) @ Id, Vgs: 8mOhm @ 52A, 10V
Power Dissipation (Max): 130W (Tc)
Vgs(th) (Max) @ Id: 3V @ 250µA
Supplier Device Package: D2PAK
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Vgs (Max): ±16V
Drain to Source Voltage (Vdss): 55 V
Gate Charge (Qg) (Max) @ Vgs: 60 nC @ 5 V
Input Capacitance (Ciss) (Max) @ Vds: 2880 pF @ 25 V

Виробник: Infineon Technologies
Description: MOSFET N-CH 30V 150A D2PAK
Packaging: Cut Tape (CT)
Package / Case: TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 150A (Tc)
Rds On (Max) @ Id, Vgs: 3.8mOhm @ 38A, 10V
Power Dissipation (Max): 140W (Tc)
Vgs(th) (Max) @ Id: 2.3V @ 250µA
Supplier Device Package: D2PAK
Part Status: Not For New Designs
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 30 V
Gate Charge (Qg) (Max) @ Vgs: 47 nC @ 4.5 V
Input Capacitance (Ciss) (Max) @ Vds: 4170 pF @ 15 V

Виробник: Infineon Technologies
Description: MOSFET N-CH 30V 105A D2PAK
Packaging: Cut Tape (CT)
Package / Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 105A (Tc)
Rds On (Max) @ Id, Vgs: 6mOhm @ 21A, 10V
Power Dissipation (Max): 110W (Tc)
Vgs(th) (Max) @ Id: 2.25V @ 250µA
Supplier Device Package: D2PAK
Part Status: Obsolete
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 30 V
Gate Charge (Qg) (Max) @ Vgs: 35 nC @ 4.5 V
Input Capacitance (Ciss) (Max) @ Vds: 2840 pF @ 15 V

Виробник: Infineon Technologies
Description: MOSFET N-CH 55V 5A SOT223
Packaging: Cut Tape (CT)
Package / Case: TO-261-4, TO-261AA
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 5A (Tc)
Rds On (Max) @ Id, Vgs: 60mOhm @ 3A, 10V
Power Dissipation (Max): 1W (Ta)
Vgs(th) (Max) @ Id: 3V @ 250µA
Supplier Device Package: SOT-223
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Vgs (Max): ±16V
Drain to Source Voltage (Vdss): 55 V
Gate Charge (Qg) (Max) @ Vgs: 11 nC @ 5 V
Input Capacitance (Ciss) (Max) @ Vds: 380 pF @ 25 V

Виробник: Infineon Technologies
Description: MOSFET P-CH 30V 3A MICRO3/SOT23
Packaging: Cut Tape (CT)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: P-Channel
Current - Continuous Drain (Id) @ 25°C: 3A (Ta)
Rds On (Max) @ Id, Vgs: 98mOhm @ 3A, 10V
Power Dissipation (Max): 1.25W (Ta)
Vgs(th) (Max) @ Id: 2.5V @ 250µA
Supplier Device Package: Micro3™/SOT-23
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 30 V
Gate Charge (Qg) (Max) @ Vgs: 14 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 510 pF @ 25 V

Виробник: Infineon Technologies
Description: MOSFET N-CH 55V 42A DPAK
Packaging: Cut Tape (CT)
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 42A (Tc)
Rds On (Max) @ Id, Vgs: 13.5mOhm @ 36A, 10V
Power Dissipation (Max): 110W (Tc)
Vgs(th) (Max) @ Id: 3V @ 250µA
Supplier Device Package: TO-252AA (DPAK)
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Vgs (Max): ±16V
Drain to Source Voltage (Vdss): 55 V
Gate Charge (Qg) (Max) @ Vgs: 35 nC @ 5 V
Input Capacitance (Ciss) (Max) @ Vds: 1570 pF @ 25 V

Виробник: Infineon Technologies
Description: MOSFET N-CH 55V 25A DPAK
Packaging: Cut Tape (CT)
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 25A (Tc)
Rds On (Max) @ Id, Vgs: 37mOhm @ 15A, 10V
Power Dissipation (Max): 57W (Tc)
Vgs(th) (Max) @ Id: 3V @ 250µA
Supplier Device Package: TO-252AA (DPAK)
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 5V, 10V
Vgs (Max): ±16V
Drain to Source Voltage (Vdss): 55 V
Gate Charge (Qg) (Max) @ Vgs: 20 nC @ 5 V
Input Capacitance (Ciss) (Max) @ Vds: 710 pF @ 25 V

Виробник: Infineon Technologies
Description: MOSFET N-CH 55V 30A DPAK
Packaging: Cut Tape (CT)
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 30A (Tc)
Rds On (Max) @ Id, Vgs: 14mOhm @ 30A, 10V
Power Dissipation (Max): 120W (Tc)
Vgs(th) (Max) @ Id: 3V @ 250µA
Supplier Device Package: TO-252AA (DPAK)
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 5V, 10V
Vgs (Max): ±16V
Drain to Source Voltage (Vdss): 55 V
Gate Charge (Qg) (Max) @ Vgs: 92 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 1870 pF @ 25 V

Виробник: Infineon Technologies
Description: MOSFET N-CH 55V 30A D2PAK
Packaging: Cut Tape (CT)
Package / Case: TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 30A (Tc)
Rds On (Max) @ Id, Vgs: 35mOhm @ 16A, 10V
Power Dissipation (Max): 3.8W (Ta), 68W (Tc)
Vgs(th) (Max) @ Id: 2V @ 250µA
Supplier Device Package: D2PAK
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 4V, 10V
Vgs (Max): ±16V
Drain to Source Voltage (Vdss): 55 V
Gate Charge (Qg) (Max) @ Vgs: 25 nC @ 5 V
Input Capacitance (Ciss) (Max) @ Vds: 880 pF @ 25 V

Виробник: Infineon Technologies
Description: MOSFET N-CH 55V 51A D2PAK
Packaging: Cut Tape (CT)
Package / Case: TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 51A (Tc)
Rds On (Max) @ Id, Vgs: 13.5mOhm @ 31A, 10V
Power Dissipation (Max): 80W (Tc)
Vgs(th) (Max) @ Id: 3V @ 250µA
Supplier Device Package: D2PAK
Part Status: Last Time Buy
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Vgs (Max): ±16V
Drain to Source Voltage (Vdss): 55 V
Gate Charge (Qg) (Max) @ Vgs: 36 nC @ 5 V
Input Capacitance (Ciss) (Max) @ Vds: 1620 pF @ 25 V

Виробник: Infineon Technologies
Description: IC MCU 8BIT 32KB FLASH 48SSOP
Packaging: Tube
Package / Case: 48-BSSOP (0.295", 7.50mm Width)
Mounting Type: Surface Mount
Speed: 50MHz
Program Memory Size: 32KB (32K x 8)
RAM Size: 4K x 8
Operating Temperature: -40°C ~ 85°C (TA)
Oscillator Type: Internal
Program Memory Type: FLASH
EEPROM Size: 1K x 8
Core Processor: 8051
Data Converters: A/D 16x12b; D/A 1x8b
Core Size: 8-Bit
Voltage - Supply (Vcc/Vdd): 1.71V ~ 5.5V
Connectivity: EBI/EMI, I2C, LINbus, SPI, UART/USART, USB
Peripherals: CapSense, DMA, LCD, POR, PWM, WDT
Supplier Device Package: 48-SSOP
Number of I/O: 25
DigiKey Programmable: Not Verified

Виробник: Infineon Technologies
Description: IC MCU 8BIT 64KB FLASH 100TQFP
Packaging: Tray
Package / Case: 100-LQFP
Mounting Type: Surface Mount
Speed: 50MHz
Program Memory Size: 64KB (64K x 8)
RAM Size: 8K x 8
Operating Temperature: -40°C ~ 85°C (TA)
Oscillator Type: Internal
Program Memory Type: FLASH
EEPROM Size: 2K x 8
Core Processor: 8051
Data Converters: A/D 16x12b; D/A 1x8b
Core Size: 8-Bit
Voltage - Supply (Vcc/Vdd): 1.71V ~ 5.5V
Connectivity: EBI/EMI, I2C, LINbus, SPI, UART/USART
Peripherals: CapSense, DMA, LCD, POR, PWM, WDT
Supplier Device Package: 100-TQFP (14x14)
Number of I/O: 62
DigiKey Programmable: Not Verified
