Виробник: Infineon Technologies
Description: MOSFET 2P-CH 30V 8A 8SO
Packaging: Tape & Reel (TR)
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Mounting Type: Surface Mount
Configuration: 2 P-Channel (Dual)
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
Power - Max: 2W
Drain to Source Voltage (Vdss): 30V
Current - Continuous Drain (Id) @ 25°C: 8A
Input Capacitance (Ciss) (Max) @ Vds: 2675pF @ 25V
Rds On (Max) @ Id, Vgs: 21mOhm @ 8A, 10V
Gate Charge (Qg) (Max) @ Vgs: 78nC @ 10V
FET Feature: Logic Level Gate
Vgs(th) (Max) @ Id: 2.5V @ 250µA
Supplier Device Package: 8-SO

Виробник: Infineon Technologies
Description: SICFET N-CH 440V 111A PG-HSOF-8
Packaging: Tape & Reel (TR)
Package / Case: 8-PowerSFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: SiCFET (Silicon Carbide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 11.7A (Ta), 111A (Tc)
Rds On (Max) @ Id, Vgs: 19.1mOhm @ 27.1A, 18V
Power Dissipation (Max): 3.8W (Ta), 341W (Tc)
Vgs(th) (Max) @ Id: 5.6V @ 9.7mA
Supplier Device Package: PG-HSOF-8
Drive Voltage (Max Rds On, Min Rds On): 15V, 18V
Vgs (Max): +25V, -10V
Drain to Source Voltage (Vdss): 440 V
Gate Charge (Qg) (Max) @ Vgs: 62 nC @ 18 V
Input Capacitance (Ciss) (Max) @ Vds: 2730 pF @ 200 V

Виробник: Infineon Technologies
Description: SICFET N-CH 440V 111A PG-HSOF-8
Packaging: Cut Tape (CT)
Package / Case: 8-PowerSFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: SiCFET (Silicon Carbide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 11.7A (Ta), 111A (Tc)
Rds On (Max) @ Id, Vgs: 19.1mOhm @ 27.1A, 18V
Power Dissipation (Max): 3.8W (Ta), 341W (Tc)
Vgs(th) (Max) @ Id: 5.6V @ 9.7mA
Supplier Device Package: PG-HSOF-8
Drive Voltage (Max Rds On, Min Rds On): 15V, 18V
Vgs (Max): +25V, -10V
Drain to Source Voltage (Vdss): 440 V
Gate Charge (Qg) (Max) @ Vgs: 62 nC @ 18 V
Input Capacitance (Ciss) (Max) @ Vds: 2730 pF @ 200 V

Виробник: Infineon Technologies
Description: IC REG LINEAR 5V 150MA 8DSO
Packaging: Tape & Reel (TR)
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Output Type: Fixed
Mounting Type: Surface Mount
Current - Output: 150mA
Operating Temperature: -40°C ~ 150°C
Output Configuration: Positive
Current - Quiescent (Iq): 280 µA
Voltage - Input (Max): 45V
Number of Regulators: 1
Supplier Device Package: PG-DSO-8
Voltage - Output (Min/Fixed): 5V
Control Features: Reset
Grade: Automotive
PSRR: 70dB (100Hz)
Voltage Dropout (Max): 0.5V @ 100mA
Protection Features: Over Current, Over Temperature, Reverse Polarity, Short Circuit
Current - Supply (Max): 8 mA
Qualification: AEC-Q100

Виробник: Infineon Technologies
Description: IC REG LINEAR 5V 150MA 8DSO
Packaging: Cut Tape (CT)
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Output Type: Fixed
Mounting Type: Surface Mount
Current - Output: 150mA
Operating Temperature: -40°C ~ 150°C
Output Configuration: Positive
Current - Quiescent (Iq): 280 µA
Voltage - Input (Max): 45V
Number of Regulators: 1
Supplier Device Package: PG-DSO-8
Voltage - Output (Min/Fixed): 5V
Control Features: Reset
Grade: Automotive
PSRR: 70dB (100Hz)
Voltage Dropout (Max): 0.5V @ 100mA
Protection Features: Over Current, Over Temperature, Reverse Polarity, Short Circuit
Current - Supply (Max): 8 mA
Qualification: AEC-Q100

Виробник: Infineon Technologies
Description: TRENCH 40<-<100V
Packaging: Tape & Reel (TR)
Package / Case: 8-PowerWDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 21A (Ta), 145A (Tc)
Rds On (Max) @ Id, Vgs: 3.1mOhm @ 50A, 10V
Power Dissipation (Max): 3W (Ta), 150W (Tc)
Vgs(th) (Max) @ Id: 3.5V @ 65µA
Supplier Device Package: PG-WSON-8-2
Drive Voltage (Max Rds On, Min Rds On): 8V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 80 V
Gate Charge (Qg) (Max) @ Vgs: 44 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 3100 pF @ 40 V

Виробник: Infineon Technologies
Description: TRENCH 40<-<100V
Packaging: Tape & Reel (TR)
Package / Case: 8-PowerWDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 40A (Ta), 344A (Tc)
Rds On (Max) @ Id, Vgs: 0.9mOhm @ 50A, 10V
Power Dissipation (Max): 3W (Ta), 221W (Tc)
Vgs(th) (Max) @ Id: 3.3V @ 118µA
Supplier Device Package: PG-WSON-8-2
Drive Voltage (Max Rds On, Min Rds On): 8V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 60 V
Gate Charge (Qg) (Max) @ Vgs: 121 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 8300 pF @ 30 V

Виробник: Infineon Technologies
Description: TRENCH 40<-<100V
Packaging: Tape & Reel (TR)
Package / Case: 8-PowerWDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 27A (Ta), 230A (Tc)
Rds On (Max) @ Id, Vgs: 1.8mOhm @ 50A, 10V
Power Dissipation (Max): 3W (Ta), 217W (Tc)
Vgs(th) (Max) @ Id: 3.5V @ 114µA
Supplier Device Package: PG-WSON-8-2
Drive Voltage (Max Rds On, Min Rds On): 8V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 80 V
Gate Charge (Qg) (Max) @ Vgs: 76 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 5400 pF @ 40 V

Виробник: Infineon Technologies
Description: XMC1000
Packaging: Tape & Reel (TR)
Package / Case: 64-VFQFN Exposed Pad
Mounting Type: Surface Mount
Speed: 48MHz
Program Memory Size: 200KB (200K x 8)
RAM Size: 16K x 8
Operating Temperature: -40°C ~ 105°C (TA)
Oscillator Type: External, Internal
Program Memory Type: FLASH
Core Processor: ARM® Cortex®-M0
Data Converters: A/D 12x12b SAR
Core Size: 32-Bit
Voltage - Supply (Vcc/Vdd): 1.8V ~ 5.5V
Connectivity: I2C, LINbus, SPI, UART/USART
Peripherals: Brown-out Detect/Reset, I2S, POR, PWM, WDT
Supplier Device Package: PG-VQFN-64-6
Number of I/O: 48

Виробник: Infineon Technologies
Description: EB 2ED2410 3D 1BCS
Packaging: Bulk
Function: MOSFET
Type: Power Management
Contents: Board(s)
Utilized IC / Part: 2ED2410-EM

Виробник: Infineon Technologies
Description: TLD40203DBTOBO1
Packaging: Box
Function: LED Driver
Type: Power Management
Contents: Board(s)
Utilized IC / Part: TLD4020-3

Виробник: Infineon Technologies
Description: IC USB SW PG-TSDSO-24-32
Features: Slew Rate Controlled
Packaging: Cut Tape (CT)
Package / Case: 24-TSSOP (0.154", 3.90mm Width) Exposed Pad
Output Type: N-Channel
Mounting Type: Surface Mount
Number of Outputs: 1
Switch Type: USB Switch
Operating Temperature: -40°C ~ 150°C (TJ)
Output Configuration: High Side
Rds On (Typ): 1.7mOhm
Input Type: Non-Inverting
Voltage - Load: 4.1V ~ 28V
Voltage - Supply (Vcc/Vdd): 4.1V ~ 28V
Current - Output (Max): 27.6A
Ratio - Input:Output: 1:1
Supplier Device Package: PG-TSDSO-24-32
Fault Protection: Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage, Reverse Battery, UVLO

Виробник: Infineon Technologies
Description: IC RF AMP 1.452GHZ-1.61GHZ TSNP6
Packaging: Tape & Reel (TR)
Package / Case: 6-XFDFN
Mounting Type: Surface Mount
Frequency: 1.452GHz ~ 1.61GHz
Voltage - Supply: 1.6V ~ 3.1V
Current - Supply: 4.7mA
Noise Figure: 0.8dB ~ 4.1dB
P1dB: 8dBm
Test Frequency: 1.452GHz ~ 1.61GHz
Supplier Device Package: PG-TSNP-6-2

Виробник: Infineon Technologies
Description: SIC DISCRETE
Packaging: Tube
Package / Case: TO-247-2
Mounting Type: Through Hole
Speed: No Recovery Time > 500mA (Io)
Reverse Recovery Time (trr): 0 ns
Technology: SiC (Silicon Carbide) Schottky
Capacitance @ Vr, F: 4243pF @ 1V, 100kHz
Current - Average Rectified (Io): 186A
Supplier Device Package: PG-TO247-2-U01
Operating Temperature - Junction: -55°C ~ 175°C
Voltage - DC Reverse (Vr) (Max): 1200 V
Voltage - Forward (Vf) (Max) @ If: 1.8 V @ 75 A
Current - Reverse Leakage @ Vr: 600 µA @ 1.2 kV

Виробник: Infineon Technologies
Description: EASY STANDARD
Packaging: Tray

Виробник: Infineon Technologies
Description: SICFET N-CH 1200V 97A TO247
Packaging: Tube
Package / Case: TO-247-4
Mounting Type: Through Hole
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: SiCFET (Silicon Carbide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 97A (Tc)
Rds On (Max) @ Id, Vgs: 17mOhm @ 40A, 18V
Power Dissipation (Max): 382W (Tc)
Vgs(th) (Max) @ Id: 5.1V @ 12.7mA
Supplier Device Package: PG-TO247-4-17
Drive Voltage (Max Rds On, Min Rds On): 15V, 18V
Vgs (Max): +23V, -7V
Drain to Source Voltage (Vdss): 1200 V
Gate Charge (Qg) (Max) @ Vgs: 89 nC @ 18 V
Input Capacitance (Ciss) (Max) @ Vds: 2910 pF @ 800 V

Виробник: Infineon Technologies
Description: PSOC4 - GENERAL
Packaging: Tray
Package / Case: 40-UFQFN Exposed Pad
Mounting Type: Surface Mount, Wettable Flank
Speed: 48MHz
Program Memory Size: 64KB (64K x 8)
RAM Size: 8K x 8
Operating Temperature: -40°C ~ 105°C (TA)
Oscillator Type: External, Internal
Program Memory Type: FLASH
Core Processor: ARM® Cortex®-M0+
Data Converters: A/D 16x10/16x12b SAR; D/A 2x7b
Core Size: 32-Bit
Voltage - Supply (Vcc/Vdd): 1.71V ~ 5.5V
Connectivity: I2C, IrDA, LINbus, Microwire, SmartCard, SPI, SSP, UART/USART
Peripherals: Brown-out Detect/Reset, DMA, POR, PWM, Temp Sensor, TRNG, WDT
Supplier Device Package: 40-QFN (6x6)
Grade: Automotive
Number of I/O: 40
Qualification: AEC-Q100

Виробник: Infineon Technologies
Description: PSOC4 - GENERAL
Packaging: Tape & Reel (TR)
Package / Case: 40-UFQFN Exposed Pad
Mounting Type: Surface Mount, Wettable Flank
Speed: 48MHz
Program Memory Size: 64KB (64K x 8)
RAM Size: 8K x 8
Operating Temperature: -40°C ~ 105°C (TA)
Oscillator Type: External, Internal
Program Memory Type: FLASH
Core Processor: ARM® Cortex®-M0+
Data Converters: A/D 16x10/16x12b SAR; D/A 2x7b
Core Size: 32-Bit
Voltage - Supply (Vcc/Vdd): 1.71V ~ 5.5V
Connectivity: I2C, IrDA, LINbus, Microwire, SmartCard, SPI, SSP, UART/USART
Peripherals: Brown-out Detect/Reset, DMA, POR, PWM, Temp Sensor, TRNG, WDT
Supplier Device Package: 40-QFN (6x6)
Grade: Automotive
Number of I/O: 40
Qualification: AEC-Q100

Виробник: Infineon Technologies
Description: PSOC4 - GENERAL
Packaging: Tray
Package / Case: 48-VFQFN Exposed Pad
Mounting Type: Surface Mount, Wettable Flank
Speed: 48MHz
Program Memory Size: 128KB (128K x 8)
RAM Size: 16K x 8
Operating Temperature: -40°C ~ 105°C (TA)
Oscillator Type: External, Internal
Program Memory Type: FLASH
Core Processor: ARM® Cortex®-M0+
Data Converters: A/D 16x10/16x12b SAR; D/A 2x7b
Core Size: 32-Bit
Voltage - Supply (Vcc/Vdd): 1.71V ~ 5.5V
Connectivity: I2C, IrDA, LINbus, Microwire, SmartCard, SPI, SSP, UART/USART
Peripherals: Brown-out Detect/Reset, DMA, POR, PWM, Temp Sensor, TRNG, WDT
Supplier Device Package: 48-QFN (7x7)
Grade: Automotive
Number of I/O: 40
Qualification: AEC-Q100

Виробник: Infineon Technologies
Description: PSOC4 - GENERAL
Packaging: Tape & Reel (TR)
Package / Case: 48-VFQFN Exposed Pad
Mounting Type: Surface Mount, Wettable Flank
Speed: 48MHz
Program Memory Size: 128KB (128K x 8)
RAM Size: 16K x 8
Operating Temperature: -40°C ~ 105°C (TA)
Oscillator Type: External, Internal
Program Memory Type: FLASH
Core Processor: ARM® Cortex®-M0+
Data Converters: A/D 16x10/16x12b SAR; D/A 2x7b
Core Size: 32-Bit
Voltage - Supply (Vcc/Vdd): 1.71V ~ 5.5V
Connectivity: I2C, IrDA, LINbus, Microwire, SmartCard, SPI, SSP, UART/USART
Peripherals: Brown-out Detect/Reset, DMA, POR, PWM, Temp Sensor, TRNG, WDT
Supplier Device Package: 48-QFN (7x7)
Grade: Automotive
Number of I/O: 40
Qualification: AEC-Q100

Виробник: Infineon Technologies
Description: IM68D128BV01XTMA1
Packaging: Tape & Reel (TR)
Output Type: Digital, PDM
Size / Dimension: 0.138" L x 0.104" W (3.50mm x 2.65mm)
Sensitivity: -37dB ±1dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 67.5dB
Termination: Solder Pads
Direction: Omnidirectional
Ratings: IP67 - Dust Tight, Waterproof
Port Location: Bottom
Height (Max): 0.043" (1.08mm)
Voltage - Rated: 1.8 V
Current - Supply: 5 µA
Voltage Range: 1.6 V ~ 3.465 V
Frequency Range: 10 Hz ~ 10 kHz

Виробник: Infineon Technologies
Description: IM68D128BV01XTMA1
Packaging: Cut Tape (CT)
Output Type: Digital, PDM
Size / Dimension: 0.138" L x 0.104" W (3.50mm x 2.65mm)
Sensitivity: -37dB ±1dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 67.5dB
Termination: Solder Pads
Direction: Omnidirectional
Ratings: IP67 - Dust Tight, Waterproof
Port Location: Bottom
Height (Max): 0.043" (1.08mm)
Voltage - Rated: 1.8 V
Current - Supply: 5 µA
Voltage Range: 1.6 V ~ 3.465 V
Frequency Range: 10 Hz ~ 10 kHz

Виробник: Infineon Technologies
Description: IMZA120R022M2HXKSA1
Packaging: Tube
Package / Case: TO-247-4
Mounting Type: Through Hole
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: SiCFET (Silicon Carbide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 80A (Tc)
Rds On (Max) @ Id, Vgs: 29mOhm @ 32A, 18V
Power Dissipation (Max): 329W (Tc)
Vgs(th) (Max) @ Id: 5.1V @ 10.1mA
Supplier Device Package: PG-TO247-4-8
Drive Voltage (Max Rds On, Min Rds On): 15V, 18V
Vgs (Max): +25V, -10V
Drain to Source Voltage (Vdss): 1200 V
Gate Charge (Qg) (Max) @ Vgs: 71 nC @ 18 V
Input Capacitance (Ciss) (Max) @ Vds: 2330 pF @ 800 V

Виробник: Infineon Technologies
Description: BLDC_MOTOR_CONTROL
Packaging: Tape & Reel (TR)

Виробник: Infineon Technologies
Description: MOSFET N-CH 150V 21A SUPER D2PAK
Packaging: Tube
Package / Case: Super D2-Pak
Mounting Type: Surface Mount
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 21A (Ta)
Supplier Device Package: Super D2-Pak
Drain to Source Voltage (Vdss): 150 V

Виробник: Infineon Technologies
Description: POWERSTAGE CE
Packaging: Tape & Reel (TR)

Виробник: Infineon Technologies
Description: IC SRAM 9MBIT PAR 100TQFP
Packaging: Tray
Package / Case: 100-LQFP
Mounting Type: Surface Mount
Memory Size: 9Mbit
Memory Type: Volatile
Operating Temperature: 0°C ~ 70°C (TA)
Voltage - Supply: 3.135V ~ 3.6V
Technology: SRAM - Synchronous, SDR
Clock Frequency: 100 MHz
Memory Format: SRAM
Supplier Device Package: 100-TQFP (14x20)
Memory Interface: Parallel
Access Time: 8.5 ns
Memory Organization: 256K x 36
DigiKey Programmable: Not Verified

Виробник: Infineon Technologies
Description: HYBRIDPACK DSC S MODULE WITH SIC
Packaging: Tube
Package / Case: 11-PowerDIP Module (2.091", 53.10mm)
Mounting Type: Through Hole
Configuration: 2 N-Channel (Half Bridge)
Operating Temperature: -40°C ~ 175°C (TJ)
Technology: Silicon Carbide (SiC)
Power - Max: 20mW
Drain to Source Voltage (Vdss): 1200V (1.2kV)
Current - Continuous Drain (Id) @ 25°C: 190A
Input Capacitance (Ciss) (Max) @ Vds: 10100pF @ 850V
Rds On (Max) @ Id, Vgs: 5.56mOhm @ 190A, 18V
Gate Charge (Qg) (Max) @ Vgs: 420nC @ 18V
Vgs(th) (Max) @ Id: 4.55V @ 60mA
Supplier Device Package: PG-MDIP-11-1
Grade: Automotive
Qualification: AEC-Q101

Виробник: Infineon Technologies
Description: MOSFET N-CH 650V 8.7A D2PAK
Packaging: Tape & Reel (TR)
Package / Case: TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 8.7A (Tc)
Rds On (Max) @ Id, Vgs: 420mOhm @ 3.4A, 10V
Power Dissipation (Max): 83.3W (Tc)
Vgs(th) (Max) @ Id: 4.5V @ 340µA
Supplier Device Package: PG-TO263-3
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 650 V
Gate Charge (Qg) (Max) @ Vgs: 32 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 870 pF @ 100 V

Виробник: Infineon Technologies
Description: TRAVEO-2 CLUST.2.5DGRAPH
Packaging: Tray
Package / Case: 216-LQFP Exposed Pad
Mounting Type: Surface Mount
Speed: 240MHz
Program Memory Size: 4.0625MB (4.0625M x 8)
RAM Size: 384K x 8
Operating Temperature: -40°C ~ 105°C (TA)
Program Memory Type: FLASH
EEPROM Size: 128K x 8
Core Processor: ARM® Cortex®-M0+, ARM® Cortex®-M7F
Core Size: 32-Bit Dual-Core
Voltage - Supply (Vcc/Vdd): 2.7V ~ 5.5V
Connectivity: CANbus, Ethernet, I2C, LINbus, SPI, UART/USART
Peripherals: DMA, I2S, LVD, Temp Sensor, WDT
Supplier Device Package: 216-TEQFP (24x24)
Number of I/O: 108

Виробник: Infineon Technologies
Description: TRAVEO-2 CLUST.2.5DGRAPH
Packaging: Tray
Package / Case: 327-LFBGA
Mounting Type: Surface Mount
Speed: 100MHz, 320MHz
Program Memory Size: 6.19MB (6.19M x 8)
RAM Size: 640K x 8
Operating Temperature: -40°C ~ 105°C (TA)
Oscillator Type: External, Internal
Program Memory Type: FLASH
EEPROM Size: 128K x 8
Core Processor: ARM® Cortex®-M0+, ARM® Cortex®-M7F
Data Converters: A/D 48x12b SAR
Core Size: 32-Bit Tri-Core
Voltage - Supply (Vcc/Vdd): 2.7V ~ 5.5V
Connectivity: CANbus, Ethernet, I2C, LINbus, SPI, UART/USART
Peripherals: DMA, I2S, LVD, Temp Sensor, WDT
Supplier Device Package: 327-FBGA (17x17)
Number of I/O: 168

Виробник: Infineon Technologies
Description: TRAVEO-2 CLUST.2.5DGRAPH
Packaging: Tape & Reel (TR)
Package / Case: 327-LFBGA
Mounting Type: Surface Mount
Speed: 100MHz, 320MHz
Program Memory Size: 6.19MB (6.19M x 8)
RAM Size: 640K x 8
Operating Temperature: -40°C ~ 105°C (TA)
Oscillator Type: External, Internal
Program Memory Type: FLASH
EEPROM Size: 128K x 8
Core Processor: ARM® Cortex®-M0+, ARM® Cortex®-M7F
Data Converters: A/D 48x12b SAR
Core Size: 32-Bit Tri-Core
Voltage - Supply (Vcc/Vdd): 2.7V ~ 5.5V
Connectivity: CANbus, Ethernet, I2C, LINbus, SPI, UART/USART
Peripherals: DMA, I2S, LVD, Temp Sensor, WDT
Supplier Device Package: 327-FBGA (17x17)
Number of I/O: 168

Виробник: Infineon Technologies
Description: TRAVEO-2 CLUST.2.5DGRAPH
Packaging: Tray
Package / Case: 327-LFBGA
Mounting Type: Surface Mount
Speed: 100MHz, 320MHz
Program Memory Size: 6.19MB (6.19M x 8)
RAM Size: 640K x 8
Operating Temperature: -40°C ~ 105°C (TA)
Oscillator Type: External, Internal
Program Memory Type: FLASH
EEPROM Size: 128K x 8
Core Processor: ARM® Cortex®-M0+, ARM® Cortex®-M7F
Data Converters: A/D 48x12b SAR
Core Size: 32-Bit Tri-Core
Voltage - Supply (Vcc/Vdd): 2.7V ~ 5.5V
Connectivity: CANbus, Ethernet, I2C, LINbus, SPI, UART/USART
Peripherals: DMA, I2S, LVD, Temp Sensor, WDT
Supplier Device Package: 327-FBGA (17x17)
Number of I/O: 168

Виробник: Infineon Technologies
Description: TRAVEO-2 CLUST.2.5DGRAPH
Packaging: Tape & Reel (TR)
Package / Case: 327-LFBGA
Mounting Type: Surface Mount
Speed: 100MHz, 320MHz
Program Memory Size: 6.19MB (6.19M x 8)
RAM Size: 640K x 8
Operating Temperature: -40°C ~ 105°C (TA)
Oscillator Type: External, Internal
Program Memory Type: FLASH
EEPROM Size: 128K x 8
Core Processor: ARM® Cortex®-M0+, ARM® Cortex®-M7F
Data Converters: A/D 48x12b SAR
Core Size: 32-Bit Tri-Core
Voltage - Supply (Vcc/Vdd): 2.7V ~ 5.5V
Connectivity: CANbus, Ethernet, I2C, LINbus, SPI, UART/USART
Peripherals: DMA, I2S, LVD, Temp Sensor, WDT
Supplier Device Package: 327-FBGA (17x17)
Number of I/O: 168

Виробник: Infineon Technologies
Description: TRAVEO-2 CLUST.2.5DGRAPH
Packaging: Tray
Package / Case: 327-LFBGA
Mounting Type: Surface Mount
Speed: 100MHz, 320MHz
Program Memory Size: 6.19MB (6.19M x 8)
RAM Size: 640K x 8
Operating Temperature: -40°C ~ 105°C (TA)
Oscillator Type: External, Internal
Program Memory Type: FLASH
EEPROM Size: 128K x 8
Core Processor: ARM® Cortex®-M0+, ARM® Cortex®-M7F
Data Converters: A/D 48x12b SAR
Core Size: 32-Bit Tri-Core
Voltage - Supply (Vcc/Vdd): 2.7V ~ 5.5V
Connectivity: CANbus, Ethernet, I2C, LINbus, SPI, UART/USART
Peripherals: DMA, I2S, LVD, Temp Sensor, WDT
Supplier Device Package: 327-FBGA (17x17)
Number of I/O: 168

Виробник: Infineon Technologies
Description: TRAVEO-2 CLUST.2.5DGRAPH
Packaging: Tray
Package / Case: 327-LFBGA
Mounting Type: Surface Mount
Speed: 100MHz, 320MHz
Program Memory Size: 6.19MB (6.19M x 8)
RAM Size: 640K x 8
Operating Temperature: -40°C ~ 105°C (TA)
Oscillator Type: External, Internal
Program Memory Type: FLASH
EEPROM Size: 128K x 8
Core Processor: ARM® Cortex®-M0+, ARM® Cortex®-M7F
Data Converters: A/D 48x12b SAR
Core Size: 32-Bit Tri-Core
Voltage - Supply (Vcc/Vdd): 2.7V ~ 5.5V
Connectivity: CANbus, Ethernet, I2C, LINbus, SPI, UART/USART
Peripherals: DMA, I2S, LVD, Temp Sensor, WDT
Supplier Device Package: 327-FBGA (17x17)
Number of I/O: 168

Виробник: Infineon Technologies
Description: TRAVEO-2 CLUST.2.5DGRAPH
Packaging: Tray
Package / Case: 327-LFBGA
Mounting Type: Surface Mount
Speed: 100MHz, 320MHz
Program Memory Size: 6.19MB (6.19M x 8)
RAM Size: 640K x 8
Operating Temperature: -40°C ~ 105°C (TA)
Oscillator Type: External, Internal
Program Memory Type: FLASH
EEPROM Size: 128K x 8
Core Processor: ARM® Cortex®-M0+, ARM® Cortex®-M7F
Data Converters: A/D 48x12b SAR
Core Size: 32-Bit Tri-Core
Voltage - Supply (Vcc/Vdd): 2.7V ~ 5.5V
Connectivity: CANbus, Ethernet, I2C, LINbus, SPI, UART/USART
Peripherals: DMA, I2S, LVD, Temp Sensor, WDT
Supplier Device Package: 327-FBGA (17x17)
Number of I/O: 168

Виробник: Infineon Technologies
Description: XMC1000
Packaging: Tape & Reel (TR)
Package / Case: 40-VFQFN Exposed Pad
Mounting Type: Surface Mount
Speed: 32MHz
Program Memory Size: 200KB (200K x 8)
RAM Size: 16K x 8
Operating Temperature: -40°C ~ 85°C (TA)
Oscillator Type: Internal
Program Memory Type: FLASH
Core Processor: ARM® Cortex®-M0
Data Converters: A/D 16x12b SAR
Core Size: 32-Bit
Voltage - Supply (Vcc/Vdd): 1.8V ~ 5.5V
Connectivity: I2C, LINbus, SPI, UART/USART
Peripherals: Brown-out Detect/Reset, I2S, POR, PWM, WDT
Supplier Device Package: PG-VQFN-40-13
Number of I/O: 35

Виробник: Infineon Technologies
Description: XMC1000
Packaging: Tape & Reel (TR)
Package / Case: 40-VFQFN Exposed Pad
Mounting Type: Surface Mount
Speed: 32MHz
Program Memory Size: 200KB (200K x 8)
RAM Size: 16K x 8
Operating Temperature: -40°C ~ 105°C (TA)
Oscillator Type: Internal
Program Memory Type: FLASH
Core Processor: ARM® Cortex®-M0
Data Converters: A/D 16x12b SAR
Core Size: 32-Bit
Voltage - Supply (Vcc/Vdd): 1.8V ~ 5.5V
Connectivity: I2C, LINbus, SPI, UART/USART
Peripherals: Brown-out Detect/Reset, I2S, POR, PWM, WDT
Supplier Device Package: PG-VQFN-40-13
Number of I/O: 34

Виробник: Infineon Technologies
Description: XMC1000
Packaging: Tape & Reel (TR)
Package / Case: 40-VFQFN Exposed Pad
Mounting Type: Surface Mount
Speed: 48MHz
Program Memory Size: 200KB (200K x 8)
RAM Size: 16K x 8
Operating Temperature: -40°C ~ 105°C (TA)
Oscillator Type: External, Internal
Program Memory Type: FLASH
Core Processor: ARM® Cortex®-M0
Data Converters: A/D 12x12b SAR
Core Size: 32-Bit
Voltage - Supply (Vcc/Vdd): 1.8V ~ 5.5V
Connectivity: CANbus, I2C, LINbus, SPI, UART/USART
Peripherals: Brown-out Detect/Reset, I2S, POR, PWM, WDT
Supplier Device Package: PG-VQFN-40-13
Number of I/O: 27

Виробник: Infineon Technologies
Description: XMC1000
Packaging: Tape & Reel (TR)
Package / Case: 48-VFQFN Exposed Pad
Mounting Type: Surface Mount
Speed: 48MHz
Program Memory Size: 200KB (200K x 8)
RAM Size: 16K x 8
Operating Temperature: -40°C ~ 105°C (TA)
Oscillator Type: External, Internal
Program Memory Type: FLASH
Core Processor: ARM® Cortex®-M0
Data Converters: A/D 12x12b SAR
Core Size: 32-Bit
Voltage - Supply (Vcc/Vdd): 1.8V ~ 5.5V
Connectivity: CANbus, I2C, LINbus, SPI, UART/USART
Peripherals: Brown-out Detect/Reset, I2S, LED, POR, PWM, WDT
Supplier Device Package: PG-VQFN-48-73
Number of I/O: 34

Виробник: Infineon Technologies
Description: XMC1000
Packaging: Tape & Reel (TR)
Package / Case: 64-VFQFN Exposed Pad
Mounting Type: Surface Mount
Speed: 48MHz
Program Memory Size: 200KB (200K x 8)
RAM Size: 16K x 8
Operating Temperature: -40°C ~ 105°C (TA)
Oscillator Type: External, Internal
Program Memory Type: FLASH
Core Processor: ARM® Cortex®-M0
Data Converters: A/D 12x12b SAR
Core Size: 32-Bit
Voltage - Supply (Vcc/Vdd): 1.8V ~ 5.5V
Connectivity: CANbus, I2C, LINbus, SPI, UART/USART
Peripherals: Brown-out Detect/Reset, I2S, POR, PWM, WDT
Supplier Device Package: PG-VQFN-64-6
Number of I/O: 48

Виробник: Infineon Technologies
Description: XMC1000
Packaging: Tape & Reel (TR)
Package / Case: 64-VFQFN Exposed Pad
Mounting Type: Surface Mount
Speed: 48MHz
Program Memory Size: 200KB (200K x 8)
RAM Size: 16K x 8
Operating Temperature: -40°C ~ 105°C (TA)
Oscillator Type: External, Internal
Program Memory Type: FLASH
Core Processor: ARM® Cortex®-M0
Data Converters: A/D 12x12b SAR
Core Size: 32-Bit
Voltage - Supply (Vcc/Vdd): 1.8V ~ 5.5V
Connectivity: CANbus, I2C, LINbus, SPI, UART/USART
Peripherals: Brown-out Detect/Reset, I2S, LED, POR, PWM, WDT
Supplier Device Package: PG-VQFN-64-6
Number of I/O: 48

Виробник: Infineon Technologies
Description: XMC1000
Packaging: Tape & Reel (TR)
Package / Case: 40-VFQFN Exposed Pad
Mounting Type: Surface Mount
Speed: 48MHz
Program Memory Size: 200KB (200K x 8)
RAM Size: 16K x 8
Operating Temperature: -40°C ~ 105°C (TA)
Oscillator Type: External, Internal
Program Memory Type: FLASH
Core Processor: ARM® Cortex®-M0
Data Converters: A/D 12x12b SAR
Core Size: 32-Bit
Voltage - Supply (Vcc/Vdd): 1.8V ~ 5.5V
Connectivity: CANbus, I2C, LINbus, SPI, UART/USART
Peripherals: Brown-out Detect/Reset, I2S, LED, POR, PWM, WDT
Supplier Device Package: PG-VQFN-40-13
Number of I/O: 27

Виробник: Infineon Technologies
Description: XMC1000
Packaging: Tape & Reel (TR)
Package / Case: 40-VFQFN Exposed Pad
Mounting Type: Surface Mount
Speed: 48MHz
Program Memory Size: 200KB (200K x 8)
RAM Size: 16K x 8
Operating Temperature: -40°C ~ 105°C (TA)
Oscillator Type: External, Internal
Program Memory Type: FLASH
Core Processor: ARM® Cortex®-M0
Data Converters: A/D 12x12b SAR
Core Size: 32-Bit
Voltage - Supply (Vcc/Vdd): 1.8V ~ 5.5V
Connectivity: I2C, LINbus, SPI, UART/USART
Peripherals: Brown-out Detect/Reset, I2S, POR, PWM, WDT
Supplier Device Package: PG-VQFN-40-13
Number of I/O: 27

Виробник: Infineon Technologies
Description: IC RF TXRX+MCU BLE 81FBGA
Packaging: Cut Tape (CT)
Package / Case: 81-TFBGA
Sensitivity: -91dBm
Mounting Type: Surface Mount
Frequency: 2.4GHz
Type: TxRx + MCU
Operating Temperature: 0°C ~ 70°C
Voltage - Supply: 3V
Power - Output: 10dBm
Protocol: Bluetooth v3.0
Current - Receiving: 26.4mA
Current - Transmitting: 47mA
Supplier Device Package: 81-FBGA (8x8)
RF Family/Standard: Bluetooth
Serial Interfaces: I2C, I2S, SPI, UART
DigiKey Programmable: Not Verified

Виробник: Infineon Technologies
Description: IMWH170R450M1XKSA1
Packaging: Tube
Package / Case: TO-247-3
Mounting Type: Through Hole
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: SiCFET (Silicon Carbide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 10A (Tj)
Rds On (Max) @ Id, Vgs: 390mOhm @ 2A, 15V
Power Dissipation (Max): 111W (Tc)
Vgs(th) (Max) @ Id: 5.7V @ 2.6mA
Supplier Device Package: PG-TO247-3-U04
Drive Voltage (Max Rds On, Min Rds On): 12V, 15V
Vgs (Max): 15V, 12V
Drain to Source Voltage (Vdss): 1700 V
Gate Charge (Qg) (Max) @ Vgs: 11.7 nC @ 12 V
Input Capacitance (Ciss) (Max) @ Vds: 506 pF @ 1000 V

Виробник: Infineon Technologies
Description: AURIX 1G-PSE
Packaging: Tape & Reel (TR)
Package / Case: 292-LFBGA
Mounting Type: Surface Mount
Speed: 200MHz
Program Memory Size: 4MB (4M x 8)
RAM Size: 472K x 8
Operating Temperature: -40°C ~ 150°C (TA)
Oscillator Type: External
Program Memory Type: FLASH
EEPROM Size: 64K x 8
Core Processor: TriCore™
Data Converters: A/D 60x12b SAR, Sigma-Delta
Core Size: 32-Bit 5-Core
Voltage - Supply (Vcc/Vdd): 1.17V ~ 5.5V
Connectivity: ASC, CANbus, Ethernet, FlexRay, HSSL, I2C, LINbus, MSC, PSI5, QSPI, SENT
Peripherals: DMA, POR, WDT
Supplier Device Package: PG-LFBGA-292-6

Виробник: Infineon Technologies
Description: IC MCU 32BIT 16MB FLASH 292LFBGA
Packaging: Tape & Reel (TR)
Package / Case: 292-LFBGA
Mounting Type: Surface Mount
Speed: 300MHz
Program Memory Size: 16MB (16M x 8)
RAM Size: 2.52M x 8
Operating Temperature: -40°C ~ 125°C (TA)
Oscillator Type: Internal
Program Memory Type: FLASH
EEPROM Size: 128K x 8
Core Processor: TriCore™
Core Size: 32-Bit 10-Core
Voltage - Supply (Vcc/Vdd): 2.97V ~ 5.5V
Connectivity: ASC, CANbus, Ethernet, FlexRay, HSSL, I2C, LINbus, MSC, PSI5, QSPI, SENT
Peripherals: DMA, LVDS, PWM, WDT
Supplier Device Package: PG-LFBGA-292-10

Виробник: Infineon Technologies
Description: IC MCU 32BIT 16MB FLASH 292LFBGA
Packaging: Cut Tape (CT)
Package / Case: 292-LFBGA
Mounting Type: Surface Mount
Speed: 300MHz
Program Memory Size: 16MB (16M x 8)
RAM Size: 2.52M x 8
Operating Temperature: -40°C ~ 125°C (TA)
Oscillator Type: Internal
Program Memory Type: FLASH
EEPROM Size: 128K x 8
Core Processor: TriCore™
Core Size: 32-Bit 10-Core
Voltage - Supply (Vcc/Vdd): 2.97V ~ 5.5V
Connectivity: ASC, CANbus, Ethernet, FlexRay, HSSL, I2C, LINbus, MSC, PSI5, QSPI, SENT
Peripherals: DMA, LVDS, PWM, WDT
Supplier Device Package: PG-LFBGA-292-10
