Продукція > INFINEON TECHNOLOGIES > Всі товари виробника INFINEON TECHNOLOGIES (129584) > Сторінка 759 з 2160

Виробник: Infineon Technologies
Description: IMLT40R011M2HXTMA1
Packaging: Tube
Package / Case: 16-PowerSOP Module
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: SiCFET (Silicon Carbide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 144A (Tc)
Rds On (Max) @ Id, Vgs: 14.4mOhm @ 37.1A, 18V
Power Dissipation (Max): 429W (Tc)
Vgs(th) (Max) @ Id: 5.6V @ 13.3mA
Supplier Device Package: PG-HDSOP-16-8
Drive Voltage (Max Rds On, Min Rds On): 15V, 18V
Vgs (Max): +23V, -7V
Drain to Source Voltage (Vdss): 400 V
Gate Charge (Qg) (Max) @ Vgs: 85 nC @ 18 V
Input Capacitance (Ciss) (Max) @ Vds: 2900 pF @ 200 V

Виробник: Infineon Technologies
Description: SHIELD_BTS7008-1EPZ
Packaging: Box
Function: Switch
Type: Power Management
Contents: Board(s)
Utilized IC / Part: BTS7008-1EPZ

Виробник: Infineon Technologies
Description: IC GATE DRVR LOW-SIDE 8DIP
Packaging: Tube
Package / Case: 8-DIP (0.300", 7.62mm)
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 6V ~ 20V
Input Type: Inverting
Supplier Device Package: 8-PDIP
Rise / Fall Time (Typ): 15ns, 10ns
Channel Type: Independent
Driven Configuration: Low-Side
Number of Drivers: 2
Gate Type: IGBT, MOSFET (N-Channel)
Logic Voltage - VIL, VIH: 0.8V, 2.7V
Current - Peak Output (Source, Sink): 2.3A, 3.3A
DigiKey Programmable: Not Verified

Виробник: Infineon Technologies
Description: SHIELD_XENSIV_A
Packaging: Box
Function: Carbon Dioxide (CO2), Humidity, Pressure, Radar, Temperature
Type: Sensor
Contents: Board(s)

Виробник: Infineon Technologies
Description: EVAL BOARD FOR 2EP130R
Packaging: Box
Function: Gate Driver
Type: Power Management
Contents: Board(s)
Utilized IC / Part: 2EP130R

Виробник: Infineon Technologies
Description: EVAL BOARD FOR 2EP130R
Packaging: Box
Function: Gate Driver
Type: Power Management
Contents: Board(s)
Utilized IC / Part: 2EP130R

Виробник: Infineon Technologies
Description: SHIELD_XENSIV_A
Packaging: Box
Function: Carbon Dioxide (CO2), Humidity, Pressure, Radar, Temperature
Type: Sensor
Contents: Board(s)

Виробник: Infineon Technologies
Description: EVAL BOARD FOR IAUTN08S5N012L
Packaging: Bulk
Function: MOSFET
Type: Power Management
Contents: Board(s)
Utilized IC / Part: IAUTN08S5N012L
Embedded: No

Виробник: Infineon Technologies
Description: ISC040N10NM7ATMA1
Packaging: Tape & Reel (TR)
Package / Case: 8-PowerTDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 18A (Ta), 130A (Tc)
Rds On (Max) @ Id, Vgs: 4mOhm @ 50A, 10V
Power Dissipation (Max): 3W (Ta), 150W (Tc)
Vgs(th) (Max) @ Id: 3.2V @ 66µA
Supplier Device Package: PG-TDSON-8-34
Drive Voltage (Max Rds On, Min Rds On): 7V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 100 V
Gate Charge (Qg) (Max) @ Vgs: 51 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 3600 pF @ 50 V

Виробник: Infineon Technologies
Description: ISC040N10NM7ATMA1
Packaging: Cut Tape (CT)
Package / Case: 8-PowerTDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 18A (Ta), 130A (Tc)
Rds On (Max) @ Id, Vgs: 4mOhm @ 50A, 10V
Power Dissipation (Max): 3W (Ta), 150W (Tc)
Vgs(th) (Max) @ Id: 3.2V @ 66µA
Supplier Device Package: PG-TDSON-8-34
Drive Voltage (Max Rds On, Min Rds On): 7V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 100 V
Gate Charge (Qg) (Max) @ Vgs: 51 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 3600 pF @ 50 V

Виробник: Infineon Technologies
Description: TRENCH 40<-<100V
Packaging: Cut Tape (CT)
Package / Case: 8-PowerWDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 27A (Ta), 230A (Tc)
Rds On (Max) @ Id, Vgs: 1.8mOhm @ 50A, 10V
Power Dissipation (Max): 3W (Ta), 217W (Tc)
Vgs(th) (Max) @ Id: 3.5V @ 114µA
Supplier Device Package: PG-WSON-8-2
Drive Voltage (Max Rds On, Min Rds On): 8V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 80 V
Gate Charge (Qg) (Max) @ Vgs: 76 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 5400 pF @ 40 V

Виробник: Infineon Technologies
Description: TRENCH 40<-<100V
Packaging: Cut Tape (CT)
Package / Case: 8-PowerWDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 40A (Ta), 344A (Tc)
Rds On (Max) @ Id, Vgs: 0.9mOhm @ 50A, 10V
Power Dissipation (Max): 3W (Ta), 221W (Tc)
Vgs(th) (Max) @ Id: 3.3V @ 118µA
Supplier Device Package: PG-WSON-8-2
Drive Voltage (Max Rds On, Min Rds On): 8V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 60 V
Gate Charge (Qg) (Max) @ Vgs: 121 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 8300 pF @ 30 V

Виробник: Infineon Technologies
Description: ISC016N08NM8SCATMA1
Packaging: Tape & Reel (TR)
Package / Case: 8-PowerWDFN
Mounting Type: Surface Mount
Supplier Device Package: PG-WSON-8-2

Виробник: Infineon Technologies
Description: ISC016N08NM8SCATMA1
Packaging: Cut Tape (CT)
Package / Case: 8-PowerWDFN
Mounting Type: Surface Mount
Supplier Device Package: PG-WSON-8-2

Виробник: Infineon Technologies
Description: TRENCH >=100V
Packaging: Cut Tape (CT)
Package / Case: 8-PowerTDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 8.8A (Ta), 50A (Tc)
Rds On (Max) @ Id, Vgs: 15.6mOhm @ 16A, 15V
Power Dissipation (Max): 3W (Ta), 95W (Tc)
Vgs(th) (Max) @ Id: 4V @ 35µA
Supplier Device Package: PG-TDSON-8-45
Drive Voltage (Max Rds On, Min Rds On): 8V, 15V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 150 V
Gate Charge (Qg) (Max) @ Vgs: 18.5 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 1300 pF @ 75 V

Виробник: Infineon Technologies
Description: MOSFET N-CH 55V 51A TO262
Packaging: Tube
Package / Case: TO-262-3 Long Leads, I2PAK, TO-262AA
Mounting Type: Through Hole
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 51A (Tc)
Rds On (Max) @ Id, Vgs: 13.9mOhm @ 31A, 10V
Power Dissipation (Max): 80W (Tc)
Vgs(th) (Max) @ Id: 4V @ 250µA
Supplier Device Package: TO-262
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 55 V
Gate Charge (Qg) (Max) @ Vgs: 43 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 1420 pF @ 25 V

Виробник: Infineon Technologies
Description: IGBT MODULE 1700V 650A
Packaging: Bulk
Package / Case: Module
Mounting Type: Chassis Mount
Input: Standard
Configuration: Half Bridge Inverter
Operating Temperature: -40°C ~ 150°C (TJ)
NTC Thermistor: Yes
IGBT Type: Trench Field Stop
Current - Collector (Ic) (Max): 650 A
Voltage - Collector Emitter Breakdown (Max): 1700 V
Current - Collector Cutoff (Max): 5 mA
Input Capacitance (Cies) @ Vce: 54000 pF @ 25 V

Виробник: Infineon Technologies
Description: MOSFET
Packaging: Tray

Виробник: Infineon Technologies
Description: MOSFET N-CH 700V 10A TO220
Packaging: Bulk
Package / Case: TO-220-3 Full Pack
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 10A (Tc)
Rds On (Max) @ Id, Vgs: 450mOhm @ 2.3A, 10V
Power Dissipation (Max): 22.7W (Tc)
Vgs(th) (Max) @ Id: 3.5V @ 120µA
Supplier Device Package: PG-TO220-FP
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±16V
Drain to Source Voltage (Vdss): 700 V
Gate Charge (Qg) (Max) @ Vgs: 13.1 nC @ 400 V
Input Capacitance (Ciss) (Max) @ Vds: 424 pF @ 400 V

Виробник: Infineon Technologies
Description: MOSFET N-CH 950V 14A TO251-3
Packaging: Tube
Package / Case: TO-251-3 Short Leads, IPak, TO-251AA
Mounting Type: Through Hole
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 14A (Tc)
Rds On (Max) @ Id, Vgs: 450mOhm @ 7.2A, 10V
Power Dissipation (Max): 104W (Tc)
Vgs(th) (Max) @ Id: 3.5V @ 360µA
Supplier Device Package: PG-TO251-3
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 950 V
Gate Charge (Qg) (Max) @ Vgs: 35 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 1053 pF @ 400 V

Виробник: Infineon Technologies
Description: IC GATE DRVR HALF-BRIDGE 14DIP
Packaging: Bulk
Package / Case: 14-DIP (0.300", 7.62mm)
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 10V ~ 20V
Input Type: Inverting, Non-Inverting
High Side Voltage - Max (Bootstrap): 600 V
Supplier Device Package: 14-DIP
Rise / Fall Time (Typ): 100ns, 35ns
Channel Type: Independent
Driven Configuration: Half-Bridge
Number of Drivers: 2
Gate Type: IGBT, MOSFET (N-Channel)
Logic Voltage - VIL, VIH: 0.8V, 2.5V
Current - Peak Output (Source, Sink): 290mA, 600mA
DigiKey Programmable: Not Verified

Виробник: Infineon Technologies
Description: IC GATE DRVR HALF-BRIDGE 14DIP
Packaging: Tube
Package / Case: 14-DIP (0.300", 7.62mm)
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 10V ~ 20V
Input Type: Inverting, Non-Inverting
High Side Voltage - Max (Bootstrap): 600 V
Supplier Device Package: 14-DIP
Rise / Fall Time (Typ): 100ns, 35ns
Channel Type: Independent
Driven Configuration: Half-Bridge
Number of Drivers: 2
Gate Type: IGBT, MOSFET (N-Channel)
Logic Voltage - VIL, VIH: 0.8V, 2.5V
Current - Peak Output (Source, Sink): 290mA, 600mA
DigiKey Programmable: Not Verified

Виробник: Infineon Technologies
Description: IC GATE DRVR HI/LOW SIDE 8DIP
Packaging: Tube
Package / Case: 8-DIP (0.300", 7.62mm)
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 10V ~ 20V
Input Type: Non-Inverting
High Side Voltage - Max (Bootstrap): 600 V
Supplier Device Package: 8-PDIP
Rise / Fall Time (Typ): 70ns, 35ns
Channel Type: Independent
Driven Configuration: High-Side or Low-Side
Number of Drivers: 2
Gate Type: IGBT, MOSFET (N-Channel)
Logic Voltage - VIL, VIH: 0.8V, 2.5V
Current - Peak Output (Source, Sink): 290mA, 600mA
DigiKey Programmable: Not Verified

Виробник: Infineon Technologies
Description: IC GATE DRVR HALF-BRIDGE 8DIP
Packaging: Tube
Package / Case: 8-DIP (0.300", 7.62mm)
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 10V ~ 20V
Input Type: Non-Inverting
High Side Voltage - Max (Bootstrap): 600 V
Supplier Device Package: 8-PDIP
Rise / Fall Time (Typ): 100ns, 35ns
Channel Type: Synchronous
Driven Configuration: Half-Bridge
Number of Drivers: 2
Gate Type: IGBT, MOSFET (N-Channel)
Logic Voltage - VIL, VIH: 0.8V, 2.5V
Current - Peak Output (Source, Sink): 290mA, 600mA
DigiKey Programmable: Not Verified

Виробник: Infineon Technologies
Description: IC GATE DRVR HALF-BRIDGE 14DIP
Packaging: Tube
Package / Case: 14-DIP (0.300", 7.62mm)
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 10V ~ 20V
Input Type: Non-Inverting
High Side Voltage - Max (Bootstrap): 600 V
Supplier Device Package: 14-DIP
Rise / Fall Time (Typ): 100ns, 35ns
Channel Type: Synchronous
Driven Configuration: Half-Bridge
Number of Drivers: 2
Gate Type: IGBT, MOSFET (N-Channel)
Logic Voltage - VIL, VIH: 0.8V, 2.5V
Current - Peak Output (Source, Sink): 290mA, 600mA
DigiKey Programmable: Not Verified

Виробник: Infineon Technologies
Description: AIKYX200N75CP2ALSA1
Packaging: Tube
Package / Case: TO-247-4
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Vce(on) (Max) @ Vge, Ic: 1.55V @ 15V, 200A
Supplier Device Package: PG-TO247-4-13
Td (on/off) @ 25°C: 79ns/268ns
Switching Energy: 7.6mJ (on), 6.4mJ (off)
Test Condition: 470V, 200A, 5Ohm, 15V
Gate Charge: 1.27 µC
Grade: Automotive
Current - Collector (Ic) (Max): 250 A
Voltage - Collector Emitter Breakdown (Max): 750 V
Current - Collector Pulsed (Icm): 600 A
Power - Max: 938 W
Qualification: AEC-Q101

Виробник: Infineon Technologies
Description: AIKYX160N75CP2ALSA1
Packaging: Tube
Package / Case: TO-247-4
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Vce(on) (Max) @ Vge, Ic: 1.55V @ 15V, 160A
Supplier Device Package: PG-TO247-4-13
Td (on/off) @ 25°C: 64ns/234ns
Switching Energy: 5.5mJ (on), 4.9mJ (off)
Test Condition: 470V, 160A, 5Ohm, 15V
Gate Charge: 975 nC
Grade: Automotive
Current - Collector (Ic) (Max): 200 A
Voltage - Collector Emitter Breakdown (Max): 750 V
Current - Collector Pulsed (Icm): 480 A
Power - Max: 750 W
Qualification: AEC-Q101

Виробник: Infineon Technologies
Description: TRENCH 40<-<100V
Packaging: Cut Tape (CT)
Package / Case: 8-PowerVDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 24A (Ta), 149A (Tc)
Rds On (Max) @ Id, Vgs: 2.3mOhm @ 20A, 10V
Power Dissipation (Max): 2.5W (Ta), 100W (Tc)
Vgs(th) (Max) @ Id: 2.3V @ 38µA
Supplier Device Package: PG-TSDSON-8-34
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 60 V
Gate Charge (Qg) (Max) @ Vgs: 61 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 4200 pF @ 30 V

Виробник: Infineon Technologies
Description: TRENCH 40<-<100V
Packaging: Cut Tape (CT)
Package / Case: 8-PowerVDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 22A (Ta), 137A (Tc)
Rds On (Max) @ Id, Vgs: 2.5mOhm @ 20A, 10V
Power Dissipation (Max): 2.5W (Ta), 100W (Tc)
Vgs(th) (Max) @ Id: 3.3V @ 38µA
Supplier Device Package: PG-TSDSON-8-34
Drive Voltage (Max Rds On, Min Rds On): 8V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 60 V
Gate Charge (Qg) (Max) @ Vgs: 40 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 2700 pF @ 30 V

Виробник: Infineon Technologies
Description: TRENCH 40<-<100V
Packaging: Cut Tape (CT)
Package / Case: 8-PowerTDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 25A (Ta), 143A (Tc)
Rds On (Max) @ Id, Vgs: 2.5mOhm @ 20A, 10V
Power Dissipation (Max): 3W (Ta), 100W (Tc)
Vgs(th) (Max) @ Id: 2.3V @ 38µA
Supplier Device Package: PG-TDSON-8
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 60 V
Gate Charge (Qg) (Max) @ Vgs: 61 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 4200 pF @ 30 V

Виробник: Infineon Technologies
Description: MOSFET_(75V 120V( PG-TDSON-8
Packaging: Cut Tape (CT)
Package / Case: 8-PowerTDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 132A (Tj)
Rds On (Max) @ Id, Vgs: 3.4mOhm @ 50A, 10V
Power Dissipation (Max): 136W (Tc)
Vgs(th) (Max) @ Id: 3.8V @ 78µA
Supplier Device Package: PG-TDSON-8-34
Grade: Automotive
Drive Voltage (Max Rds On, Min Rds On): 6V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 80 V
Gate Charge (Qg) (Max) @ Vgs: 66 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 4559 pF @ 40 V
Qualification: AEC-Q101

Виробник: Infineon Technologies
Description: IC FRAM 256KBIT PARALLEL 32STSOP
Packaging: Tape & Reel (TR)
Package / Case: 32-TFSOP (0.465", 11.80mm Width)
Mounting Type: Surface Mount
Memory Size: 256Kbit
Memory Type: Non-Volatile
Operating Temperature: -40°C ~ 85°C (TA)
Voltage - Supply: 2V ~ 3.6V
Technology: FRAM (Ferroelectric RAM)
Memory Format: FRAM
Supplier Device Package: 32-sTSOP
Write Cycle Time - Word, Page: 140ns
Memory Interface: Parallel
Access Time: 140 ns
Memory Organization: 32K x 8
DigiKey Programmable: Not Verified

Виробник: Infineon Technologies
Description: INDUSTRY 14
Packaging: Tube
Package / Case: TO-247-3
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Reverse Recovery Time (trr): 105 ns
Vce(on) (Max) @ Vge, Ic: 1.75V @ 15V, 100A
Supplier Device Package: PG-TO247-3-32
IGBT Type: Trench Field Stop
Td (on/off) @ 25°C: 31ns/237ns
Switching Energy: 3.2mJ (on), 1.8mJ (off)
Test Condition: 400V, 100A, 10Ohm, 15V
Gate Charge: 205 nC
Current - Collector (Ic) (Max): 140 A
Voltage - Collector Emitter Breakdown (Max): 750 V
Current - Collector Pulsed (Icm): 400 A
Power - Max: 429 W

Виробник: Infineon Technologies
Description: TRENCH >=100V
Packaging: Tape & Reel (TR)
Package / Case: 8-PowerTDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 6.4A (Ta), 24A (Tc)
Rds On (Max) @ Id, Vgs: 32mOhm @ 9A, 10V
Power Dissipation (Max): 3W (Ta), 43W (Tc)
Vgs(th) (Max) @ Id: 2.2V @ 11µA
Supplier Device Package: SuperSO8
Drive Voltage (Max Rds On, Min Rds On): 3.3V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 120 V
Gate Charge (Qg) (Max) @ Vgs: 10.1 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 650 pF @ 60 V

Виробник: Infineon Technologies
Description: TRENCH >=100V
Packaging: Cut Tape (CT)
Package / Case: 8-PowerTDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 6.4A (Ta), 24A (Tc)
Rds On (Max) @ Id, Vgs: 32mOhm @ 9A, 10V
Power Dissipation (Max): 3W (Ta), 43W (Tc)
Vgs(th) (Max) @ Id: 2.2V @ 11µA
Supplier Device Package: SuperSO8
Drive Voltage (Max Rds On, Min Rds On): 3.3V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 120 V
Gate Charge (Qg) (Max) @ Vgs: 10.1 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 650 pF @ 60 V

Виробник: Infineon Technologies
Description: IC FANOUT DIST 16TSSOP
Packaging: Tube
Package / Case: 16-TSSOP (0.173", 4.40mm Width)
Mounting Type: Surface Mount
Output: LVCMOS
Frequency - Max: 166.7MHz
Type: Fanout Distribution, Multiplexer, Zero Delay Buffer
Input: LVCMOS, LVTTL, Crystal
Operating Temperature: 0°C ~ 70°C
Voltage - Supply: 2.5V, 3.3V
Ratio - Input:Output: 3:4
Differential - Input:Output: No/No
Supplier Device Package: 16-TSSOP
PLL: Yes with Bypass
Divider/Multiplier: No/No
Number of Circuits: 1
DigiKey Programmable: Not Verified

Виробник: Infineon Technologies
Description: DCDC CONTROLLER
Packaging: Tape & Reel (TR)

Виробник: Infineon Technologies
Description: IC POWER SW PG-HSOF-8-6
Packaging: Tape & Reel (TR)
Package / Case: 8-PowerSFN
Output Type: N-Channel
Mounting Type: Surface Mount
Number of Outputs: 1
Switch Type: General Purpose
Operating Temperature: -40°C ~ 150°C (TJ)
Output Configuration: High Side
Rds On (Typ): 6mOhm
Input Type: Non-Inverting
Voltage - Load: 8V ~ 60V
Voltage - Supply (Vcc/Vdd): Not Required
Current - Output (Max): 15.9A
Ratio - Input:Output: 1:1
Supplier Device Package: PG-HSOF-8-6
Fault Protection: Current Limiting (Fixed), Over Load, Over Temperature, Over Voltage, Short Circuit
Grade: Automotive
Qualification: AEC-Q100

Виробник: Infineon Technologies
Description: IC POWER SW PG-HSOF-8-6
Packaging: Cut Tape (CT)
Package / Case: 8-PowerSFN
Output Type: N-Channel
Mounting Type: Surface Mount
Number of Outputs: 1
Switch Type: General Purpose
Operating Temperature: -40°C ~ 150°C (TJ)
Output Configuration: High Side
Rds On (Typ): 6mOhm
Input Type: Non-Inverting
Voltage - Load: 8V ~ 60V
Voltage - Supply (Vcc/Vdd): Not Required
Current - Output (Max): 15.9A
Ratio - Input:Output: 1:1
Supplier Device Package: PG-HSOF-8-6
Fault Protection: Current Limiting (Fixed), Over Load, Over Temperature, Over Voltage, Short Circuit
Grade: Automotive
Qualification: AEC-Q100

Виробник: Infineon Technologies
Description: TRENCH 40<-<100V
Packaging: Cut Tape (CT)
Package / Case: 8-PowerTDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 15.2A (Ta), 62A (Tc)
Rds On (Max) @ Id, Vgs: 6mOhm @ 10A, 10V
Power Dissipation (Max): 3W (Ta), 50W (Tc)
Vgs(th) (Max) @ Id: 3.3V @ 14µA
Supplier Device Package: PG-TDSON-8
Drive Voltage (Max Rds On, Min Rds On): 8V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 60 V
Gate Charge (Qg) (Max) @ Vgs: 15.5 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 1000 pF @ 30 V

Виробник: Infineon Technologies
Description: IC MCU 16BIT 320KB FLASH 64LQFP
Packaging: Tape & Reel (TR)
Package / Case: 64-LQFP Exposed Pad
Mounting Type: Surface Mount
Speed: 80MHz
Program Memory Size: 320KB (320K x 8)
RAM Size: 34K x 8
Operating Temperature: -40°C ~ 85°C (TA)
Oscillator Type: Internal
Program Memory Type: FLASH
Core Processor: C166SV2
Data Converters: A/D 9x10b
Core Size: 16-Bit
Voltage - Supply (Vcc/Vdd): 3V ~ 5.5V
Connectivity: CANbus, EBI/EMI, I2C, LINbus, SPI, SSC, UART/USART, USI
Peripherals: I2S, POR, PWM, WDT
Supplier Device Package: PG-LQFP-64-6
Number of I/O: 40
DigiKey Programmable: Not Verified

Виробник: Infineon Technologies
Description: IC MCU 16BIT 192KB FLASH 64LQFP
Packaging: Tape & Reel (TR)
Package / Case: 64-LQFP Exposed Pad
Mounting Type: Surface Mount
Speed: 80MHz
Program Memory Size: 192KB (192K x 8)
RAM Size: 26K x 8
Operating Temperature: -40°C ~ 125°C (TA)
Oscillator Type: Internal
Program Memory Type: FLASH
Core Processor: C166SV2
Data Converters: A/D 9x10b
Core Size: 16-Bit
Voltage - Supply (Vcc/Vdd): 3V ~ 5.5V
Connectivity: CANbus, EBI/EMI, I2C, LINbus, SPI, SSC, UART/USART, USI
Peripherals: I2S, POR, PWM, WDT
Supplier Device Package: PG-LQFP-64-6
Number of I/O: 40
DigiKey Programmable: Not Verified

Виробник: Infineon Technologies
Description: IC MCU 16/32B 320KB FLASH 64LQFP
Packaging: Tape & Reel (TR)
Package / Case: 64-LQFP Exposed Pad
Mounting Type: Surface Mount
Speed: 80MHz
Program Memory Size: 320KB (320K x 8)
RAM Size: 34K x 8
Operating Temperature: -40°C ~ 125°C (TA)
Oscillator Type: Internal
Program Memory Type: FLASH
Core Processor: C166SV2
Data Converters: A/D 9x10b
Core Size: 16/32-Bit
Voltage - Supply (Vcc/Vdd): 3V ~ 5.5V
Connectivity: CANbus, EBI/EMI, I2C, LINbus, SPI, SSC, UART/USART, USI
Peripherals: I2S, POR, PWM, WDT
Supplier Device Package: PG-LQFP-64-6
Number of I/O: 38
DigiKey Programmable: Not Verified

Виробник: Infineon Technologies
Description: IC MCU 32BIT 32KB FLASH 24QFN
Packaging: Tape & Reel (TR)
Package / Case: 24-UFQFN Exposed Pad
Mounting Type: Surface Mount
Speed: 24MHz
Program Memory Size: 32KB (32K x 8)
RAM Size: 4K x 8
Operating Temperature: -40°C ~ 85°C (TA)
Oscillator Type: Internal
Program Memory Type: FLASH
Core Processor: ARM® Cortex®-M0+
Data Converters: A/D 1x10b
Core Size: 32-Bit
Voltage - Supply (Vcc/Vdd): 1.71V ~ 5.5V
Connectivity: I2C, IrDA, LINbus, Microwire, SmartCard, SPI, SSP, UART/USART
Peripherals: Brown-out Detect/Reset, CapSense, LCD, LVD, POR, PWM, WDT
Supplier Device Package: 24-QFN (4x4)
Number of I/O: 19
DigiKey Programmable: Not Verified

Виробник: Infineon Technologies
Description: IC MCU 32BIT 32KB FLASH 24QFN
Packaging: Cut Tape (CT)
Package / Case: 24-UFQFN Exposed Pad
Mounting Type: Surface Mount
Speed: 24MHz
Program Memory Size: 32KB (32K x 8)
RAM Size: 4K x 8
Operating Temperature: -40°C ~ 85°C (TA)
Oscillator Type: Internal
Program Memory Type: FLASH
Core Processor: ARM® Cortex®-M0+
Data Converters: A/D 1x10b
Core Size: 32-Bit
Voltage - Supply (Vcc/Vdd): 1.71V ~ 5.5V
Connectivity: I2C, IrDA, LINbus, Microwire, SmartCard, SPI, SSP, UART/USART
Peripherals: Brown-out Detect/Reset, CapSense, LCD, LVD, POR, PWM, WDT
Supplier Device Package: 24-QFN (4x4)
Number of I/O: 19
DigiKey Programmable: Not Verified

Виробник: Infineon Technologies
Description: PSOC4 - GENERAL
Packaging: Tray
Package / Case: 24-UFQFN Exposed Pad
Mounting Type: Surface Mount, Wettable Flank
Speed: 24MHz
Program Memory Size: 32KB (32K x 8)
RAM Size: 4K x 8
Operating Temperature: -40°C ~ 85°C (TA)
Oscillator Type: Internal
Program Memory Type: FLASH
Core Processor: ARM® Cortex®-M0+
Data Converters: A/D 16x10b SAR; D/A 1x7b, 1x8b
Core Size: 32-Bit
Voltage - Supply (Vcc/Vdd): 1.71V ~ 5.5V
Connectivity: I2C, IrDA, LINbus, Microwire, SmartCard, SPI, SSP, UART/USART
Peripherals: Brown-out Detect/Reset, CapSense, LCD, POR, PWM, WDT
Supplier Device Package: 24-QFN (4x4)
Grade: Automotive
Number of I/O: 19
Qualification: AEC-Q100
